CONNECTING POWER CORD

1. Plug the supplied power cord into the machine and
attach the power cord to the strain relief clip as
shown (Figure 7).
FOR SAFETY: Do not operate machine unless
power cord is properly grounded. Only use the
manufacturer- supplied power cord which is
designed exclusively for this machine. Do not use
additional extension cords.
2. Plug the power cord into a properly grounded wall
outlet (Figure 8).
FIG. 7
WARNING: Electrical Hazard, Do Not Operate
With Damaged Power Cord.
If the power cord is damaged or broken, it must be
replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a
hazard.
3. Wrap the power cord around the handle and cord
hook when storing machine. To remove power
cord, turn the cord hook upward (Figure 9).
Tennant E5 (03- 08)
Grounded
3 Hole Outlet
Grounded Pin
FIG. 8
FIG. 9

MACHINE OPERATION

FOR SAFETY: Do not operate machine unless
operator manual is read and understood.

PRE- OPERATION

1. Inspect power cord for damage.
2. Vacuum the carpet and remove debris from area.
3. Using a pump- up sprayer, spray the carpet with an
approved pre-treatment detergent (Figure 10).
Contact your dealer for recommended cleaning
detergents.
FIG. 10
WARNING: Fire Or Explosion Hazard. Do Not
Use Flammable Materials. Only Use Commercially
Available Floor Cleaners intended for machine
application.

CLEANING CARPETS

WARNING: Fire or Explosion Hazard, Do Not
Use or Pick Up Flammable Materials.
1. Pull the handle adjustment lever and adjust the
handle to a comfortable operating height (Figure
11). Release the lever to lock the position.
FIG. 11
OPERATION
EN
7
