Spare Parts/Accessories; Technical Specifications - Grizzly ARM 2433-20 Traduction De La Notice D'utilisation Originale

GB
water. Damaged batteries may
damage the environment and your
health if toxic fumes or liquids leak
out.
• Dispose of the equipment with the
battery discharged. Do not open the
equipment or the battery.
• Dispose of the equipment in ac-
cordance with the local regulations.
Take the equipment to a collection
point,where it will be recycled in an
environmentally friendly manner. For
information about this, ask your local
waste management company or our
service centre.
• Throw the cut grass on the compost.
Do not throw it in the normal house-
hold waste.
• Defective units returned to us will be
disposed of for free.

Spare parts/Accessories

Spare parts and accessories
can be obtained at
www.grizzly-service.eu
If you do not have internet access, please
contact the Service Centre (see "Grizzly
Service-Center").

Technical Specifications

Cordless lawnmower .......ARM 2433-20
Motor voltage ......................24 V
Idling speed ..............................3650 min
Cutting circle ................................ 330 mm
Cut height ............................... 25 - 65 mm
Protection class ..................................... III
Protection type ..................................IPX1
Weight
(without battery and recharger) .....13.4 kg
34
Lawn bag volume ................................32 l
Sound pressure specification
(L )..........................78.8 dB(A); K
pA
Noise level specification (L
measured ..........89.1 dB(A); K
guaranteed ................................. 91 dB(A)
Vibration (a
Battery (Li-Ion) .......................... AP 2403
Nominal voltage.............................24 V
Capacity ......................................... 3.0 Ah
Energy ......................................... 64.8 Wh
Charging time .................... approx. 3 - 5 h
Recharger ...................................... SC 24
Voltage
input ............ 100-240 V~, 50-60 Hz, 30 W
Voltage output ....................24 V
Protection class .................................
Protection category ...........................IPX0
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to
compare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure
assessment.
Warning:
The vibration emission value may differ
during actual use of the power tool from
the stated value depending on the manner
in which the power tool is used.
Safety precautions aimed at protecting
3,0 Ah the user should be based on estimated
exposure under actual usage conditions
-1
(all parts of the operating cycle are to be
considered, including, for example, times
during which the power tool is turned off
and times when the tool is turned on but is
running idle).
)
WA
) ...........1.45 m/s
2
h
=3 dB
pA
=2.17 dB
WA
; K=1.5 m/s
2
0.75 A
II
