Operating your French Door Refrigerator

USING THE CONTROL PANEL

RFG297**, RFG29P**
1
2
3
10
( 1 ) Energy ( 1 ) Energy
Touching this button turns Energy Saver
mode on and off. When you turn Energy
Saver Saver
Saver on, the Energy Saver icon lights.
Turn Energy Saver off and the icon goes
off. The Energy Saver function automatically
turns on. when power is supplied to the
refrigerator.
If condensation or water drops appear on
the doors, turn the Energy Saver mode off.
Touch this button to set the freezer to your
( 2 ) Freezer ( 2 ) Freezer
desired temperature.
(Hold 3 (Hold 3
You can set the temperature between
sec for sec for
-8°F and 8°F (between -22°C and -14°C).
Power Power
Touch and hold this button for 3 seconds
to decrease the time needed to freeze
Freeze) Freeze)
products in the Freezer. It can be helpful
if you need to quickly freeze easily spoiled
items or if the temperature in the freezer has
warmed dramatically (For example, if the
door was left open).
( 3 ) Alarm / ( 3 ) Alarm /
This button serves two purposes:
hold 3 sec hold 3 sec
1) To turn the door open alarm on and off
for Filter for Filter
If the door alarm is set to On, an alarm
Reset Reset
beeps if any refrigerator door is left open
for more than three minutes.
The beeping stops when you close the
door. The door alarm function is pre-
set to On in the factory. You can turn it
off by touching and then releasing this
button. You can turn it back on in the
same fashion. The icon lights up when the
function is on.
2) To reset the water fi lter life indicator.
After you replace the water fi lter, touch
and hold this button for 3 seconds to reset
the water fi lter life indicator.
DA68-02488A.indb 섹션11:11 DA68-02488A.indb 섹션11:11
4
5
6
7 8 9
RFG296**, RFG298**, RFG29T**
1
2
3
10 7
( 4 ) Lighting/ ( 4 ) Lighting/
Touching this button turns on the Dispenser
Hold 3 Hold 3
LED lamp (under the display) in continuous
sec for sec for
mode so that it stays on continuously.
C C ↔ ↔ F F
The button also lights up. If you want the
Dispenser lamp to come on only when some
one uses the dispenser, touch this button
to turn the continuous mode off. Touch and
hold this button for 3 seconds to switch the
temperature units between °C and °F.
( 5 ) Fridge ( 5 ) Fridge
Touch this button to set the fridge to your
(Hold (Hold desired temperature. You can set the
temperature between 34°F and 46°F
3sec for 3sec for
(between 7°C and 1°C).
Power Power
Touch and hold this button for 3 seconds to
Cool) Cool)
decrease the time needed to cool products
in the Refrigerator.
It can be helpful if you need to quickly cool
easily spoiled items or if the temperature
in the fridge has warmed dramatically (For
example, if the door was left open).
( 6 ) Ice Off ( 6 ) Ice Off If you don't want to make more ice, touch
this button. Also, pressing this button for 3
(Hold 3 (Hold 3
seconds turns on Child Lock which locks
sec for sec for
the display panel and dispenser buttons so
child lock) child lock)
the buttons can not be used. The Child Lock
icon lights up to indicate you've activated
the Child Lock function. Press 3 seconds to
unlock.
Touch this button to select your desired
( 7 ) Ice Type ( 7 ) Ice Type
ice type. Cubed and crushed ice modes
alternate when you press the button.
This mode can not be used with the Water
mode simultaneously.
(Cubed) (Crushed) (Cubed) (Crushed)
( 8 ) Water ( 8 ) Water
Touch this button to dispense water. This
mode can not be used with the Ice Type
mode simultaneously. Water Water mode will
be off if you touch the Ice Type button.
Water Water
4
5
6
8 9
