2. ICE BUCKET

To remove - Lift the ice bucket ( 1 ).
To relocate - Place the ice bucket into the Super
extended drawer ( 2 ).
1
3. Super Extended Drawer
To remove - Pull the drawer out to full extension.
Tilt up the rear of the drawer and lift straight out.
To relocate - Place the drawer onto the rails ( 4 ) by
tilting it up. Lower the drawer into place until it is
horizontal and slide the Drawer ( 3 ) in.
3
DA68-02488A.indb 섹션4:19 DA68-02488A.indb 섹션4:19
2
4

4. Freezer Drawer

To remove the freezer drawer -
Pull the freezer drawer out fully. Tilt up the rear of
the bin and lift it out to remove.
To relocate the freezer drawer -
Place the bin into the rail assembly.
Do not allow babies or children go inside
the freezer drawer. They could damage the
CAUTION
refrigerator and seriously injure themselves.
Do not sit on the freezer door. The door may
break. Do not allow children to climb into the
freezer drawer.
Do not remove the divider.
CAUTION
If trapped inside, children may be injured or
suffocate to death.
WARNING
Operating _19
