Controlling the fridge temperature
The fridge temperature can be set between between
34°F and 46°F (or between 7°C and 1°C) to suit your
particular needs. Press the Fridge button repeatedly
until the desired temperature is shown in the
temperature display. The temperature will change by
2°F (or 1°C) with each press. See below.
Fahrenheit : 38°F ➞ 36°F ➞ 34°F ➞ 46°F ➞ 44°F ➞
42°F ➞ 40°F ➞ 38°F.
Centigrade : 3°C ➞ 2°C ➞ 1°C ➞ 7°C ➞ 6°C ➞ 5°C
➞ 4°C ➞ 3°C.
The temperature control process for the Fridge works
just like the Freezer process. Press the Fridge button
to set your desired temperature. After a few seconds,
the Fridge will begin adjusting towards the newly set
temperature. This will be refl ected in the digital display.
Recommend Temp (Fridge) : 38°F (or 3°C ) Recommend Temp (Fridge) : 38°F (or 3°C )
- The temperature of the Freezer, Fridge or Pantry
Room may rise when you open the doors too
frequently, or if a large amount of warm or hot food
is placed inside.
- This may cause the digital display to blink. Once the
freezer and Fridge temperature return to their normal
set temperatures, the blinking will stop.
- If the blinking continues, you may need to "reset"
the refrigerator. Try unplugging the appliance, wait
for around 10 minutes and then plug the power cord
back in.
- If there is a communication error between the
Display and Main Controller, the Pantry Display light
may blink. If the blinking continues for a long period
of time, please contact a Samsung Electronics
Service Center.
USING THE COLD WATER
DISPENSER
Push the appropriate ice type button to
select what you want dispensed.
14_ operating
DA68-02488A.indb 섹션9:14 DA68-02488A.indb 섹션9:14
Using the ice Dispenser
Place a glass underneath the ice
dispenser and push gently against the
dispenser lever with your glass.
Make sure the glass is in line with
the dispenser to prevent the ice from
bouncing out.
Please wait 2 seconds before
removing the glass under the
CAUTION
dispenser to prevent spills.
If the Refrigerator door opens, the Dispenser does not
work.
When Cubed Ice is selected after using the
Crushed Ice mode, a small amount of residual
CAUTION
crushed ice might be produced.
Do not pull the lever out. You could damage
or break the lever's spring.
CAUTION
• To clean the ice bin/
bucket, wash with a
mild detergent, rinse
well, and dry thoroughly
it. Do not use harsh or
abrasive cleaners or
solvents.
• When you select
Cubed Ice after using
the Crushed Ice mode,
a small amount of
residual crushed ice might be produced.
• If ice doesn't come out, pull out the ice bucket and
press the test button located on the right side of ice
maker.
• Do not press the test button continuously when the
tray is fi lled with ice or water. Water may overfl ow or
ice may jam the bucket.
• Normal Use
To fi ll the ice bucket to maximum capacity after
installation, follow these steps:
1. Allow your refrigerator to operate and cool down
for 24 hours (or 1 full day).
- Waiting 24 hours will allow your ice maker to
cool properly.
NO ICE NO ICE
Select this if you want to Select this if you want to
turn ice maker off turn ice maker off
check the check the
water level water level
Test button Test button
