Used Symbols; Information On Intellectual Property; Functional Description And Specifications - Dremel 3D40 Traduction De La Notice Originale

USED SYMBOLS

Symbol Name
Warning symbol
WARNING
!
Read manual
symbol
THIS IS A CLASS A PRODUCT. IN
WARNING
!
A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN
WHICH CASE THE USER MAY BE REQUIRED TO
TAKE ADEQUATE MEASURES.
INFORMATION ON INTELLECTUAL
PROPERTY
The Dremel 3D40 is intended for 3D printing objects
from digital files that you create or own, or have the
right to print using the Dremel 3D40. When making
objects using the Dremel 3D40, it is your responsibility
to ensure that you do not infringe any third party
intellectual property rights or violate any applicable
laws or regulations, such as U.S. or foreign intellectual
property laws. The Dremel 3D40 may not be used to
make objects protected by intellectual property rights
owned by third parties without such third parties'
permission. Using the Dremel 3D40 to do any of the
following may require the permission of third parties:
to make a duplicate or facsimile (in whole or in part) of
any object not created by you, to make an object from
a digital file you do not own, or to make an object from
a scan of a physical object that you did not create. It is
your responsibility to obtain such permission. In some
cases, you may not be able to obtain such permission.
Where such permission cannot be obtained, you
should not 3D print such object, or you do so at your
own risk. You may not modify, reverse engineer,
decompile, or disassemble the Dremel 3D40 or its
software or firmware, except as permitted by applicable
law. If you use the Dremel 3D40 in any way other than
as recommended and described in these Operating/
Safety Instructions, you do so at your own risk. Using
the Dremel 3D40 to make objects that infringe any
intellectual property rights owned by third parties could
result in civil or criminal prosecution and penalties,
and you could be liable for money damages, fines, or
imprisonment.
Designation/
Explanation
Alerts user to warning
messages
Extruder: Single extrusion
Extruder temperature: Up to 230°C (397°F)
Alerts user to read
Operating Interface: 3.5" full color IPS touch screen
manual
Maximum Build Volume: 10" x 6" x 6.7" (255mm x
155mm x 170mm)
Layer Thickness: 4 mil | 0.004 inches 100 microns |
0.10 mm
Filament Colors: See Dremel3D.com for color choices
Internal Storage: 4GB
External Storage: USB Flash Drive
Weight (without spool): 16kg (35lbs)
Dimensions: 20.25" x 16" x 15.9" (515mm x 406mm x
394mm)
ONLY works with Dremel 1.75mm filament
All polymers degrade with time. Do not unpack until
filament is needed. Filament should be stored at room
temperature: 16-29° C (60-85° F) and in dry conditions.
Dremel 3D40 comes with complimentary Dremel
Digilab 3D Slicing software for Windows and Mac
OSX. This application converts your 3D digital files into
buildable files.
•
•
•
•
•
•
•
•
4
FUNCTIONAL DESCRIPTION AND
SPECIFICATIONS
BUILDING
WEIGHT & DIMENSIONS
FILAMENT
FILAMENT STORAGE
SOFTWARE
SUPPORTED OPERATING SYSTEMS
Apple Mac OS X v10.9 or later (Mavericks)
® ® ®
Microsoft Windows 8.1
® ®
Microsoft Windows 7 SP1
® ®
MINIMUM SYSTEM SPECIFICATIONS
CPU: 64-bit processor (32-bit not supported)
Memory: 3 GB RAM (4 GB or more recommended)
Disk space: ~2 GB free disk space for installation
Display card: 1,024 MB GDDR RAM or more.
Microsoft Direct3D 11 capable graphics card or
® ®
higher
Pointing device: Three-button mouse
