3.2 Delivery Contents

1
Fig.: 2. Delivery contents
1. Charging column
2. Key set for key-operated push-button on the socket
panel
3. Key set for releasing the turning lever
4. Key for releasing the cover plate
5. Operating and installation manual
6

3.3 Assembly

Charging column Basic S 22
1
2
2
3
3
4
5
4
6
5
Fig.: 3. Charging column / socket panel
1. Cover plate
2. Socket panel (2x)
3. Basic enclosure
4. Front plate
5. Profile strips
6. Inspection window
7. Key-operated push-button
8. Charging socket type 2 (mode 3)
9. Charging socket SCHUKO® (mode 1)
7
8
9
