V u e é c l a t é e - 2 0 2 0 P I K E S e l e c t
Retaining screw
Low speed compression
adjuster knob
Compression
damper top cap
Crown
Orifices de purge de l'huile
(x1 ou x6)
Internal floating piston (IFP)
Compression damper
Cartridge tube
Dust wiper seal
Rebound damper piston
Rebound damper shaft
Rebound damper seal head
Foam ring
Maxle Stealth
Crush washer
Bottom bolt
Rebound adjuster knob
Steerer tube
Air cap
Air valve
Air spring top cap
Bottomless Token(s)
(optional)
(35 mm - grey)
Upper tube
Brake hose guide
Air spring piston
Top out bumper
Air spring seal head
Retaining ring
Vue éclatée - 2020 PIKE Select
Unité du ressort
pneumatique
Unité de la cartouche
de compression
Unité de la cartouche
de détente
Lower leg
Air spring shaft
Air spring shaft nut
Crush washer
Bottom bolt
14
