2.1.2 Electrical installation
There are different clock versions: IMPULSE MIN 24V, MIN 1V5 , AFNOR or RADIO.
Refer to the product label to determine which version you have.
The lighting (if option chosen) is always powered via a mains power supply.
2.1.2.1 IMPULSE MIN 24V - MIN 1V5 model
Run
the
synchronisation
1
through the small central cable gland
then connect this cable to the terminal
block in terminals 1 and 2 SYNC.
Make sure to observe the correct
wiring:
white
brown
Attach this cable to the fixing plate
2
with a cable retainer.
2.1.2.2 AFNOR model
Run a mains cable through the right-
1
hand cable gland then connect this
cable to the terminal block in the
L-N-
terminals dedicated to the
electronic card (icon
has the lighting option, the 2 mains
cables must come from the same
building.
Connect this mains cable to the fixing
2
plate with a cable retainer.
3
Run the synchronisation power cable
through the smallest central cable
gland.
Connect this cable to the electronic
4
card via the terminal block
stencilled AF.
There is no need to observe polarity.
5
Connect the backup battery cable (if
present) to the electronic card.
Check the position of the dips on the
6
electronic card (see opposite).
28
cable
white
brown
(Impulse network)
) If the clock
Ø 1,5 mm
2
IMPULSE
AFNOR
Ø 1,5 mm
EN
L N
DIPs
2
230 V
