1. INITIAL CHECKS
Thank you for choosing a Bodet clock. This product has been carefully designed to ensure your
satisfaction, adhering to quality processes ISO9001 and ISO14001.
We recommend that you read this manual carefully before installing the product.
Retain this manual throughout the lifespan of your product so that you can refer to it when
necessary.
Failure to observe these instructions may cause irreversible damage and invalidate the warranty.
In that case, BODET cannot be held liable.
Non-contractual data. BODET reserves the right to make functional, technical or aesthetic
changes to the clocks, without prior notice.
This manual is subject to change without notice. To obtain the latest version of this documentation,
please refer to our website: www.bodet-time.com.
These instructions relate to the "IMPULSE MIN 24V, MIN 1V5, AFNOR and RADIO" models.
For other models, please refer to the corresponding instructions.
The illustrations in this manual feature the Profil 760 model.
1.1 Unpacking the clock
Carefully unpack the clock and check the contents of the package. This should include:
– the clock and this manual or a quick start guide.
– three stud bolts and three wall plugs for mounting a single-sided clock onto a wall.
Version: at the back of the clock is a product label stating the version of the clock and its electrical
characteristics.
Impulse Minute (MIN 24V): a slave clock driven by a master clock sending minute impulses on a
parallel line.
Impulse Minute (MIN 1V5): a slave clock driven by a time base from a control unit sending 1.5V
minute impulses.
AFNOR / RADIO: a slave clock driven by a master clock sending AFNOR NFS-87500A time code
messages or by a GPS or radio receiving antenna.
Depending on the clock model (Profil 750, 760 or 780) the position of the components inside
the clock may change.
1.2 Cleaning
Use an anti-static product. Never use alcohol, acetone or other solvents which may damage the
clock's casing or glass. After manipulating the clock, the seals should be cleaned before applying a
silicone oil to make it easier to open and close the clock.
1.3 Safety instructions - Precautions for installation
Installation and maintenance of this equipment must be carried out by qualified
personnel.
1.3.1 Use of the instructions
Make sure to follow the indications given by the pictograms in this manual. The main pictograms
are identified below:
: indicates advice, a recommendation or an explanation.
: indicates that special attention needs to be paid.
: indicates that misuse or failure to follow the instructions could result in an electrical
danger. This information must be taken into account when installing or using the product.
