DISPLAY (AND DELIVERY TIME) SETTING
(T3 version only):
n the main menu, it is possible to see the temper-
atures of the units on the machine. The temper-
atures are given in both in °C and °F. The first
line shows the temperatures for units 1 and 3,
while the second line shows the temperatures of
units 2 and 4 or just the temperature for unit 2, if
there are just 3 units on the machine.
The function is opened by pressing the ENTER
key and the display will read "TEMP. DISPLAY".
Using the ▲ ▼ keys it is possible to select
"ACTIVE" or "NOT ACTIVE".
The ENTER e RESET keys serve to confirm in
the following cases:
• If "ACTIVE" is selected, this returns to the
main menu.
• If "NOT ACTIVE" is selected, this opens the
"DELIVERY TIME" function (described here
below).
• The display will read:
GRINDING
• When the ENTER key is pressed, the dis-
play will read:
GRINDING
XXX
Using the ▲ ▼ keys, it is possible to select
XXX as:
• NOT ACTIVE (pouring times will not be
shown).
• ROW 1 (pouring times will be shown in row 1).
56
• ROW 2 (pouring times will be shown in row
2).
• Press ENTER to confirm and pass to the
next step.
• Press RESET to return to the previous page
without confirming.
If the delivery time display is on when a
delivery is started - unless with the
Continuous function - the bottom line of the
display will show the delivery time (or times
if more than one unit is delivering).
Each group has an area of the bottom line:
the area on the left is for unit 1; the area
alongside it is for unit 2 and so on, until the
area on the far right, which is for unit 4.
The different areas are separated by vertical
bars; if a group is not delivering, the area is
empty.
Here below is an example: unit 1 is deliver-
ing (it has just started and 0 seconds have
passed); unit 2 has been delivering for 12
seconds and unit 4 is delivering (it has been
delivering for 21 seconds)..
Area reserved to the
Area reserved to the
delivery time of unit 2
delivery time of unit 3
Thursday
0 I 12 I
Area reserved to the
Area reserved to the
delivery time of unit 1
delivery time of unit 4
If the choice of activating the temperature dis-
play on the main page, when the power unit is
switched on or the configuration menu closed, it
is necessary to wait about a second before the
temperatures are displayed. The available tem-
perature information is as follows:
a) One temperature: the current unit temperature;
b) "LOW": the temperature of the unit is below
70°C;
c) "N.C.":the temperature probe is not connect-
ed;
d) "C.C.": the temperature probe has short circuited.
DELIVERY WHILE WASHING
It is possible to activate or not, the possibility to
quit the menu with the ENTER key during a
washing cycle to allow pouring.
When choosing to quit the washing function to
be able to use the units not being washed for
pouring as required, the washing cycle will be
shown in the bottom or top line, depending on
the choices made from the "POURING TIME"
menu. If the pouring times are deactivated, the
washing process will be viewed on the bottom
line.
During an automatic washing cycle, off the
menu (therefore, with pouring enabled), it is not
possible to enter the setting menu to switch off
the machine either in manual or automatic
mode.
The function is opened by pressing the ENTER
key.
Using the ▲ ▼ keys, it is possible to select
between the NOT ACTIVE / ACTIVE options.
The ENTER key serves to confirm and return to
the main menu.
12:00
Pressing the RESET key returns to the main
menu and any changes are not saved.
I 21
PROGRAMMING THE POURING TIME (Digit
version only)
• The ADONIS Digit is equipped with an elec-
tronic system to control delivery times
according to the coffee grinding fineness.
• The display will read:
• When the ENTER key is pressed, the display
GRINDING
