maintenance
EN
13.7 night light replacement
Your appliance comes equipped with our Night Light ™. The light has been pre-wired and can be controlled from
the switch on the control panel.
It is recommended that the Night Light ™ be in the "OFF" position when the appliance is on.
In the event the lamp or lens needs to be replaced:
•
Unplug the light from inside the appliance.
•
Remove the 4 screws that secure the lens frame. This frame retains the glass lens.
•
The lamp can now be accessed. It will pull straight out of the socket.
•
Replace the lamp with Wolf Steel parts only, as lamp and lens are special
"high temperature" products.
•
When re-installing, ensure integrity of gasket seal.
THE FIREBOX MUST BE SEALED.
"Light leakage" from the upper area may be noticed. The holes in the lamp housing are necessary for ventilation
and must not be covered.
Gasket
Lens*
Frame
*Install lens smooth side towards the frame.
70
W415-4127 / B-0 / 03.25.24
note:
Do not handle the lamp (bulb) with bare fingers as it may be
hot. Use a clean, dry cloth for protection.
note:
Do not over-tighten the screws, as this could break the lens.
