finishing
EN
11.6 safety barrier installation / removal
To remove the safety barrier from the appliance carefully lift it up and off the shoulder screws.
A.
Place the safety barrier onto the appliance by lifting it up and hooking onto the side shoulder screws.
B.
Adjust to fit snug against the finish material. Ensure safety barrier is installed correctly.
11.7 firebox glass door installation / removal
WARNING
!
•
Do not insert fingers in the gap between the door and the door frame, or between the spring latches & door.
there is a risk of injury due to the spring mechanism. Do not insert fingers in the spring door latch mechanism.
Side view
Door trim
Remove the safety screen assembly, refer to the "safety barrier installation / removal" section for
A.
details
Remove the door trim by carefully lifting it up and off from behind the bottom frame of the glass door.
B.
For door removal, locate the top and bottom door latches. Pull latches forwards and away to disengage
C.
door latches.
note:
58
W415-4127 / B-0 / 03.25.24
Door frame
Ensure to leave one hand on the glass door during entire door removal.
TLV50L Illustrated
