9.0 nailing tab installation
nailing tab installation
EN
IMPORTANT: If the front frame was removed, it must be reinstalled prior to installing
the nailing tabs.
1
Remove the screws from the appliance.
3
Type 1 (x2)
Secure to the upper front frame using 2 screws (supplied).
note:
See "venting", "electrical information" and "gas installation" sections prior to finish framing.
IMPORTANT: Do NOT remove
the knockouts unless installing
Dynamic Heat Control™/Ducted
Heat Management™. If damaged
or removed without Dynamic
Heat Control™/Ducted Heat
Management™, appliance will
overheat and will cause a fire hazard.
48
W415-4127 / B-0 / 03.25.24
DO NOT DISCARD.
2
Align the nailing tab with the holes on the appliance, secure
with the screws in step 1.
TOP VIEW
4
X X
XX
