4-12. Connecting Weld Cable
1
3
4-13. Installing And Threading Welding Wire
1
WOOD
OM-221 687 Page 18
From Wire Feeder
2
2
6 in.
(150 mm)
Pull and hold wire; cut off end.
Tighten
Clockwise
1
Follow wire manufacturer's recom-
mendations for weld cable polarity.
2
3
Push female connector over male
connector, and turn 1/4 turn clock-
wise.
Installing Wire And Adjusting
.
Hub Tension:
Hold wire tightly
1
to keep it from
unraveling.
2
Remove retaining ring, and install
spool so hub pin fits spool hole. Re-
install retaining nut.
Adjust tension nut so only a slight
force is needed to turn spool.
Threading Welding Wire:
3
Lay gun cable out straight.
Open pressure assembly, hold wire
tightly, and cut off end. Push wire
through guides into gun.
Close and tighten pressure assem-
3
bly. Press Jog switch until wire
comes out gun.
Feed wire against wooden surface,
and tighten knob so wire does not
slip.
Cut off wire, and close door.
User-Suppled Weld Cable
User-Suppled Male Connector
User-Suppled Female
Connector
804 211-A
Retaining Nut
Hub Tension Adjustment
Screw
Pressure Assembly
Adjustment Knob
Tools Needed:
9/16 in.
804 212-A
