ENGLISH
2) Fixing mode with brackets (optional accessories)
Two different optional accesories are available under request:
• 20.695 - BRACKETS KIT VORT PIV QUADRO: fixed height version, for installing the unit directly on the loft
floor (fig. 9A) or to joists or special battens installed in the loft (fig. 9B).
• 20.460 - ADJUSTABLE BRACKETS KIT VORT PIV QUADRO: manually height adjustable version (fig. 10)
which allows to install the unit above the loft insulation.
9
10
Adjustable
height
210÷320 mm
A B
11
