Refer to section 10. b) for instructions on how to program the speed controller.
Important!
When using a LiPo vehicle battery, remember to check whether undervoltage detection is enabled on the
speed controller (normally 3.2 V/cell). If undervoltage detection is disabled, the LiPo may be permanently
damaged due to overdischarge.
When using a NiMH battery, disable undervoltage detection or configure a lower voltage setting (see sec-
tion 10. b).
The LED on the speed controller switches off when the throttle is in the neutral position and turns red when the
forwards/reverse throttle is engaged. An additional green LED turns on when the vehicle is moving forwards at full
throttle.
g) Attaching and fastening the car body
Now put the car body on the brackets and fasten it with the safety clips that were removed at the start.
