71
 Do NOT allow the cuff to be twisted or bended.
 Do NOT twist the cuff hose or put heavy things on it.
 Please hold the connector of the hose while pulling out or plugging in it to the device.
 It's recommended that the patient should take measurement again when arrhythmia
or auricular fibrillation occurs.
 The patient should sit or lay down with calm condition and make the cuff and the patient's
heart on the same level to get accurate measurement. Other positions may lead to
inaccurate measurement.
2.3.2 SpO Measurement
2
Operation procedure:
1. Connect the smart SpO 2 probe to the connector
on the upper-side of the device with mark of "PORT1"
or "PORT2". When unplugging the connector, be sure
to hold the head of the connector and pull it out.
2. Red light blinking inside the clip of SpO
means successful connection.
3. Insert one finger (index finger is preferred, the nail
should be not too long) into the clip of the probe
according to the finger mark on the probe, shown at the side.
4. The device begins to make measurement.
probe
2
ENGLISH
Figure 2.6 demonstration for SpO probe
2
