Table 1 ECG Leads Configuration and Electrodes Location Table
Electrode Location
The intersection between the centerline
of the right clavicle and Rib 2.
The intersection between the centerline
of the left clavicle and Rib 2.
Between the left edge of the breast
bone and Rib 5
2.4 Blood Pressure Accuracy Check Method
Operation procedure:
1. Unscrew the M3x6 screw from the battery compartment on the back of the Spot-Check
Monitor, as shown in figure 2.11.
2. Take a NIBP connector plug from the battery cover, as shown in figure 2.12. (Note: there
are two plugs but you will only need one.)
3. Air Path Connection: Take a piece of air tube (0.5~1m long, Ø8.0mm/Ø4.0mm diameter).
Attach the NIBP connector with a connector plug on to one end of the air tube. Connect
the other end to the 3-way connector. Connect the other 2 ends of the 3-way connector
to a Mercury Sphygmomanometer as shown in Figure 2.13.
4. Connect the NIBP connector end to the NIBP port on the Spot-Check Monitor as shown in
figure 2.14.
ENGLISH
Lead
Lead I
Lead II
Electrode Name& Color
R (Red)/
R (Red)/
RA (White)
RA (White)
F (Green)/
L (Yellow)/
LL (Red)
LA (Black)
L (Yellow)/
F (Green)/
LA (Black)
LL (Red)
82
Lead III
L (Yellow)/
LA (Black)
R (Red)/
RA (White)
F (Green)/
LL (Red)
