6. PROGRAMMING

6.1 INSTALLATION MENU

When the control panel is switched on, after showing the messages DITEC and microprocessor and card FW VERSION,
the device automatically enters the installation menu and displays the message SELECT LANGUAGE.
Confirm with
Remove cables from PIN 3, 4, 20 during programming
STEP 1 level options
st
1
Select language
Confirm with:
2
Door model
Confirm with:
3
Position control
Confirm with:
4
Calibrating positions
Confirm with:
5
Command mode
Confirm with:
6
CONFIRM DATA
PROGRAMMING COMPLETED
The door is now programmed and operating with the set default speed values.
With the door MOVING, the voltage and current values will be displayed on the BUS.
0DT866 10-05-2022
2 level options
nd
ENGLISH
ITALIAN
FRANÇAIS
DEUTCH
ESPANOL - POLSKA
CESKY - MAGYAR
SOFT RESET
SECTOR RESET
SMART PLUS
SECTOR PLUS
TRAFFIC C
SMART RESET
LIMIT SWITCH
ENCODER
CLOSED POSITION
PARTIAL POSITION
(indicates the deceleration start
position)
OPEN POSITION
IMPULSIVE
MAN PRESENT
INPUT 1-9
Menu scrolling
- 24 -
Notes
Confirm with:
Confirm with:
Confirm the Limit Switch option
with:
The door will move to the required
position in operator present mode and
at low speed.
Confirm the Limit Switch position after
setting
Confirm with:
Selecting 1-9: if 1-9 is closed, the
command mode will be impulsive, if
1-9 is open the command mode will be
"dead man"
Confirm with:
