FIELD TEST DEVICE sigfox RC2 - Guide utilisateur / User guide version V1.0.0
Example of a set of commands and corresponding responses that can be seen on the terminal:
Syntaxe de la Commande
\FF\FF\FF\FF+++
ATS380=3600
ATS380?
FR
AT&W
ATO
Interpreting the previous example: the user modifies the frame transmission period. The register 380 is verified and the parameters are saved
before exiting. When exiting command mode, the device will start a new transmission cycle.
EN

5.4. Register description

Once supplied with power, the Field Test Device will function according to the last saved configuration (factory settings if this is the first time
the device has been switched on, or if this configuration has not been changed).
ATS<n>=<m> or ATR type modification commands allow you to modify the content of these ranges.
It is essential to save the parameters using the AT&W command before exiting the command mode, otherwise all of your changes will be lost.
IMPORTANT: The registers that are not documented (that can appear in the list following the AT/S command) in
the paragraphs that follow are reserved and must not be changed.
The below list of registers allows to change the behaviour of the product.
Details on how each register works can be found after the table.
Range
S370
S371
S380
S832
S383
S385
S386
S387
S388
All manuals and user guides at all-guides.com
Description
Input request in command mode
Changing the frame transmission period
Return the value of the S380 register
Memory request for the state range
Output request in command mode
Content
RESERVE
GPS configuration
Frame transmission period
Communication mode
RESERVE
Personnalized Payload Size
Personalize Payload Text - Bloc 1
Personalize Payload Text - Bloc 2
Personalize Payload Text - Bloc 3
Syntaxe de la réponse à la ligne suivante
CM
O
S380=3600
O
O
Default value
1
0: GPS deactivated
1: GPS activated/Continuous Mode
12
0x00000101: GPS activated/Continuous Mode + GPS
Reset (Cold Start)
0: No periodic transmission
600
1 to 86400 (expressed in seconds) : Periodic transmission
0: monodirectional
1
1: bidirectional
1
0 : Deactivated
0
1 to 12 : Size of the payload
0
Each bloc allow to define 4 bytes of the payload
0
The data enter in the last bloc will be not take in charge
0
Comments
