FIELD TEST DEVICE sigfox RC2 - Guide utilisateur / User guide version V1.0.0

1. INTRODUCING THE DEVICE

1.1. Description

The Field Test Device (FTD) from adeunis® is a Class 0 sigfox compatible device. This is not a point to point device and may not be used in this
manner. This indicates that it must be used on sigfox operate network.
The sigfox Field Test Device from adeunis® is a ready-to-use device, which makes it possible to communicate with all network using the sigfox
FR
protocol. The system makes it possible to transmit and receive radio frames and to instantly view the results.
Equipped with a large LCD screen, you can view various information relating to how the network being used is functioning (Uplink, Downlink,
PER, etc.) in addition to information from sensors (GPS coordinates, temperature, battery level, etc.). This device is specifically adapted for appli-
cation validation, such as communicating sensors, tracking, smart building, metering, security and M2M.
Thanks to its rechargeable battery, the FTD allows several hours of functioning and can be recharged using a standard mobile phone micro-usb.
EN

1.2. Mechanical features

Unit specifications

Dimensions
Weight
Materials
All manuals and user guides at all-guides.com
H186.20 x L75.20 x P22.80
140g
Unit: ABS GP22 + Black Colouring (HB à 1.6mm)
Lexan: Autotex Polycarbonate
Antenna: Thermolast K TC7AA (d) (a) UL#E214855
75.20mm
22.80mm
