4.4. Longitude
Hex
00
FR
55
34
50
EN
Note: the value expressed in the payload will be in degrees, minutes and fractions of a second. A conversion to degrees, minutes and seconds
must be carried out in order to make a comparison with the coordinates displayed on the device's LCD screen.
4.5. UL counter
If S382=1, bidirectional mode :
Hex
Decimal
20
32
If S382=0, monodirectional mode :
Hex
Decimal
20
8224
20
Please note: This counter is not the sigfox stack frame counter, but an internal frame counter. Therefore, there is no correlation between this
counter and the one that you can view on the network.
4.6. DL counter
If S382=1, bidirectional mode :
Hex
Decimal
20
32
Please note: This counter is not the sigfox stack frame counter, but an internal frame counter. Therefore, there is no correlation between this
counter and the one that you can view on the network.
If S382=0, monodirectional mode : no information on UL counter (absent in the frame).
All manuals and user guides at all-guides.com
N°order
Bit N°
7..4
BCD coding of the entire degree section (one hundredth of a degree)
3..0
BCD coding of the entire degree section (one tenth of a degree)
7..4
BCD coding of the entire degree section (whole degrees)
3..0
BCD coding of the entire minute section (one tenth of a minute)
7..4
BCD coding of the entire minute section (whole minutes)
4
3..0
BCD coding of the decimal section (tenth)
7..4
BCD coding of the decimal section (one hundredth)
3...1
Not used
0
Hemispheric coding
Number
N°order
of bytes
5
1
Uplink frame counter
Number of
N°order
bytes
5
2
Uplink frame counter
Number of
N°order
bytes
6
2
Downlink frame counter
Commentaires
Comments
Comments
Comments
Valeur
005°53,450
005°53,450
005°53,450
005°53,450
005°53,450
005°53,450
005°53,450
0 : Est
1 : Ouest
Value
0 ... 255
Value
0 ... 65 535
Valeur
0 ... 255
Page
38
of 44
