Figures

IEC 280-315
IEC 355
IEC 400-500
Figure 1. Connection of cooling water, air plug and emptying plug and condensation drain holes.
Water Inlet R1
Water Outlet R1
Open
Drain hole
Closed
Air plug of the water
channel
Emptying plug
of the water channel
Open
Drain hole
33
