NAME OF PARTS
Models : RCD-4.0FSR, RCD-5.0FSR, RCD-6.0FSR
3
16
17
20
19
Number
1
Fan
2
Fan Motor
3
Heat Exchanger
4
Distributor
5
Strainer
6
Micro-Computer Control Expansion Valve
7
Electrical Control Box
8
Refrigerant Gas Pipe Connection (with ∅15.88 Flare Nut)
9
Refrigerant Liquid Pipe Connection (with ∅9.52 Flare Nut)
10
Drain Pipe Connection (VP25)
?
N O T E
Regarding the refrigerant cycle drawings and diagrams, refer to Technical Catalogue.
13
PMML0549 rev.1 - 02/2021 - A10761230A
1
2
1660
13
7
12
15
6
18
Part name
Viewed from P
14
11
10
P
9
8
5
4
Number
11
Drain Discharge Mechanism
12
Float Switch
13
Drain Pan
14
Rubber Plug for Drain
15
Air Panel: P-AP160DNA (sold separately)
16
Air Inlet Flat Grille
17
Air Filter
18
Air Outlet
19
Air Inlet
20
Cover for Corner Pocket
375
Part name
