GB
Technical Data
Description
Switching current
Light bulbs
High-voltage halogen lamps (HV)
Low-voltage halogen lamps (LV)
Fluorescent lamps
LED lamps
Warm-up time of
Ambient temperature
Storage temperature
Protection level
Protection class
Dimensions
Switching operations are executed in the vicinity of the zero crossing of the sine curve. This contributes to contact protec-
tion, especially when switching LEDs on and extends the service life of the motion switch. The motion switch should be
switched off if consumers are being replaced (type of consumer or other load of a consumer of the same type).
76
110°
Article No.: 823712018
5 A (cos phi = 1)
max. 1,000 W
max. 500 W
max. 250 VA
max. 300 VA
max. 150 W/VA
90 sec.
-20 °C ... +45 °C
-20 °C ... +45 °C
IP44
Class II
(129 x 80 x 63) mm
180°
Article No.: 823812011
5 A (cos phi = 1)
max. 1,000 W
max. 500 W
max. 250 VA
max. 300 VA
max. 150 W/VA
90 sec.
-20 °C ... +45 °C
-20 °C ... +45 °C
IP44
Class II
(129 x 80 x 63) mm
270°
Article No.: 822012016
8 A (cos phi = 1)
max. 1,840 W
max. 1,000 W
max. 300 VA
max. 400 VA
max. 180 W/VA
90 sec.
-20 °C ... +45 °C
-20 °C ... +45 °C
IP44
Class II
(129 x 80 x 63) mm
