GB
The switching behaviour of the mo-
tion switch is at its most reliable when
the coverage area is crossed diagonally
and not frontally to the motion switch
(see figure).
High perception
diagonally through
the coverage area
Low perception
frontally or directly
under the motion switch
Motion switch - Individual parts
Motion switch upper housing
1
Mounting plate
2
Sensor head/Lens system
3
Inner corner/Outer corner mounting
4
4
2
3
1
