Technical Information

Motor
Power - DC 12, 24, 12/24
HP (horsepower) rating
Power cable length
Power cable gauge
Power cable DC battery connectors
Amps (FLA)
RPM
Duty cycle
Thermal Protection
Circuit protection fuse
Certification
Pump
Type- rotary, diaphragm, gear, vane
Flow Rate (with supplied hose / nozzle)
Flow Rate open flow - no hose or nozzle
Max discharge pressure
Dry vac (in Hg)
Head- Max (ft)
Anti-siphon valve
Inlet - Size / Thread
Outlet – Size / Thread
Mount
Materials of construction -pump housing
Materials of construction- wetted material
Rotor materials of construction
Rotor vane material of construction
Compatible fluids
Strainer Mesh Size
Warranty (yr)
Maximum Sound Level

Motor Tag Information

The carrying handle on your RD series pump contains
important technical, performance, and certification
information. For your specific model certification,
reference the regulatory marks on your pumps
handle. Be certain this handle remains affixed to the
pump at all times.
RD8
12 VDC
1/6 HP
10'
14 AWG
Yes
14 A
3600
30 min. ON / 30 min. OFF
Yes
Yes (30 Amp Fuse)
UL/cUL Motor/CE/ATEX/IECEx Pump UL/cUL Motor/CE/ATEX/IECEx Pump
Rotary Hinged Vane
Up to 8 GPM / 30 LPM
Up to 10 GPM / 38 LPM
16 PSI
5 in vacuum
37'
None
3/4" NPT / BSPP
3/4" NPT / BSPP
2" Bung (NPT) / BSPT
Aluminum
BUNA-N + HNBR
Nylon
Acetal
Diesel, Gasoline, BioDiesel up to
B20, E15, Kerosene, Mineral Spirits,
Methanol (up to 15%)
20 x 20
2 Year
65 dB (A)
10
RD12
12 VDC
1/6 HP
10'
14 AWG
Yes
14 A
3600
30 min. ON / 30 min. OFF
Yes
Yes (30 Amp Fuse)
Rotary Hinged Vane
Up to 12 GPM / 45 LPM
Up to 13 GPM / 50 LPM
16 PSI
5 in vacuum
37'
None
3/4" NPT / BSPP
3/4" NPT / BSPP
2" Bung (NPT) / BSPT
Aluminum
BUNA-N + HNBR
Nylon
Acetal
Diesel, Gasoline, BioDiesel up to
B20, E15, Kerosene, Mineral Spirits,
Methanol (up to 15%)
20 x 20
2 Year
65 dB (A)
