Parts List
Liste de pièces
パーツリスト
Ersatzteileliste
Parts List
En
Parts #
Description
1418
GASKET FOR CYLINDER (0.2mm)
1468
WASHER SET FOR FUEL LINE FITTING
1471
MAIN NEEDLE
1473
FUEL LINE FITTING/WASHER SET
1474
IDLE ADJUSTMENT SCREW W/ SPRING
1504
GLOW PLUG COLD R5
1662
SCREW SET (8pcs)
6122
BODY PIN (6mm/MEDIUM/10pcs)
6154
NYLON STRAP (3.5x150mm/BLACK/10pcs)
6163
SERVO TAPE 20x100mm (5pcs)
6274
PRECUT FOAM BUMPER GRAY (RS4)
6807
SHOCK SHAFT 3x31mm (2pcs)
6816
SILICONE O-RING S10 (6pcs)
6819
SILICONE O-RING P-3 (RED/5pcs)
6823
SILICONE O-RING 4.5x6.6mm (RED/5pcs)
6836
SHOCK SPRING 13x29x1.55mm (BLACK/2pcs)
15107
NITRO STAR T3.0 ENGINE WITH PULLSTART
15112
CONNECTING ROD
15114
RETAINER FOR PISTON PIN (2pcs)
15127
COVER PLATE SET (ROTO STARTER/PULLSTART)
15128
COVER PLATE
15130
STARTING PIN/PRESSURE SPRING
15131
LOCK PIN FOR CARBURETOR
15132
DUST PROTECTION AND O-RING COMPLETE SET
15133
ONE WAY BEARING FOR STARTER
15140
CYLINDER/PISTON SET
15141
CYLINDER/PISTON/CONNECTING ROD SET
15142
PISTON PIN/RETAINER SET
15143
CYLINDER HEAD WITH SCREWS
15144
UNDER HEAD
15150
CRANK CASE (BLACK/T3.0)
15151
CRANKSHAFT (STANDARD SHAFT/T3.0)
15152
STARTING SHAFT (T3.0)
15162
COMPOSITE ROTARY CARBURETOR COMPLETE (F2/6.5mm)
15170
THROTTLE ARM AND NUT SET
15172
MAIN NEEDLE VALVE HOLDER
15174
MAIN NEEDLE/FUEL INTAKE SET
15176
COMPOSITE ROTARY CARBURETOR MAIN BODY (F2/6.5mm)
15177
ROTARY VALVE (F2/6.5mm)
50474
SILICONE TUBE 2x5x300mm
72001
PILOT SHAFT 4x30mm (2pcs)
72107
CUP JOINT 5x10x16mm (2pcs)
72108
CUP JOINT 5x10x16mm
72144
LINKAGE SET
72148
BRAKE CAM SHAFT/PLATE SET
72161
GEAR SHAFT 5x55mm (NITRO 2 SPEED)
75106
BODY CLIP (6mm/BLACK/20pcs)
76817
SPUR GEAR 47 TOOTH (1M) (NITRO 2 SPEED)
76843
SPUR GEAR 43 TOOTH (1M) (2 SPEED/NITRO 3)
85029
RADIO TRAY SET
85030
SUSPENSION ARM SET
85031
SHOCK TOWER/ BUMPER SET
85032
BODY POST/ LINK SET
85033
SUPPORT SET
85036
GEARBOX SET
85037
REAR HUB SET (2 DEGREE/ 1 DEGREE)
85038
FRONT UPRIGHT SET (8 DEGREE/ 10 DEGREE)
86014
GEAR DIFF BEVEL GEAR SET 10T/13T
86021
FLYWHEEL (WITH COLLET)
86022
COLLET 6x10mm
86023
DRIVE SHAFT 6x60mm
86036
DRIVE SHAFT 6x52mm (2pcs)
86037
ALUMINUM EXHAUST HEADER (BLACK)
86038
2 SPEED TRANSMISSION
86039
THREADED 2 SPEED CLUTCH BELL 12mm (NITRO 3 2 SPEED
86050
2 SPEED MAINTENANCE KIT
86329
HEAVY-DUTY FINAL GEAR SET (P1x36T/P1x14T)
86907
ALUMINUM TUNED PIPE (RIGHT MOUNT)
86910
EXHAUST COUPLING
87021
FUEL TANK WITH PRIMER (75cc)
87022
FOAM TAPE 25x60mm (3pcs)
87023
GEAR DIFF ADJUSTMENT SPRING
87028
PTFE CLUTCH SHOE AND SPRING SET
87112
CASE FOR MOTOR UNIT
87113
BATTERY LID FOR MOTOR UNIT
87114
GEAR SET FOR MOTOR UNIT
87115
MOTOR AND SWITCH SET WITH PINION FOR MOTOR UNIT
87116
STARTER SHAFT WITH O-RING
Parts #
Description
87120
HPI ROTO START SYSTEM (FOR NITRO STAR 12/15/18 PUL
87207
AIR CLEANER (12-18 SIZE)
87208
AIR CLEANER SLEEVE SET (FOR #87207)
87213
AIR CLEANER FOAM ELEMENT SET (FOR #87207)
93317
TURNBUCKLE 4-40x34mm (2pcs)
101939 PLAZMA 1.5V ALKALINE AA BATTERIES (4pcs)
102786 HPI SF-10 SERVO GEAR SET
104105 HPI SF-10W SERVO (WATERPROOF/4.5kg-cm6.0V)
104106 HPI SF-10W SERVO CASE SET
105381 HPI TF-40 2.4GHz TRANSMITTER (2ch)
105383 HPI RF-40 RECEIVER (2.4GHz/3ch)
105385 HPI TF-40 / RF-40 2.4GHz RADIO SET
106629 MAIN CHASSIS 2.5mm (6065/GUNMETAL)
106630 THREADED PINION 18Tx12mm (1M) (ORANGE)
106631 THREADED PINION 22Tx12mm (1M) (ORANGE)
106632 HEAVY DUTY 1ST GEAR ADAPTER (ORANGE/NITRO 2 SPEED)
106633 SHOCK CAP 12xM13x0.8mm (ORANGE/GROOVED/2pcs)
106634 BALL STUD 4.7x14mm (BLACK/4pcs)
106635 ARM BRACE SET (ORANGE)
A249
BALL STUD 3.8x3mm (4pcs)
A280
FLANGE SHAFT SET 3x25mm/3x30mm
A281
FLANGE SHAFT SET 3x36mm/3x42mm
A396
SERVO SAVER SET
A431
DIFF CASE
A471
SHOCK PARTS SET
A540
SHOCK BODY SET (45-56mm/2pcs)
A556
AXLE 5x32mm (FRONT/2pcs)
A557
AXLE 5x38mm (REAR/2pcs)
A558
DIFFERENTIAL SHAFT (2pcs)
A559
GEAR SHAFT 5x37mm
A770
HPI SPORT SHOCK SET 45-56mm (2pcs)
A805
PILOT SHAFT M5
A838
FLANGE PIPE 3x4.5x5.5mm (4pcs)
A875
EXHAUST GASKET (5pcs)
A880
CLUTCH BELL FOR NITRO RS4 2 SPEED
A881
CLUTCH HOLDER FOR NITRO RS4 2 SPEED
B021
BALL BEARING 5x10x4mm (2pcs)
B022
BALL BEARING 5x11x4mm (2pcs)
B030
BALL BEARING 10x15x4mm (2pcs)
B085
BALL BEARING 8x16x5mm (2pcs)
Z125
BALL CUP 4.3x15.5mm (14pcs)
Z136
BALL STUD 4.3x6.5mm (4-40/4pcs)
Z150
ANTENNA PIPE SET
Z162
HEAVY WEIGHT GREASE (#100000/GEAR DIFF)
Z164
HEAVY WEIGHT GREASE (#30000/GEAR DIFF)
Z170
SILICONE SHOCK OIL #300 (10cc)
Z224
WASHER M3x8mm (10pcs)
Z238
C CLIP 13mm (4pcs)
Z242
E CLIP E2mm (20pcs)
Z251
SPRING PIN 1.5x8mm (10pcs)
Z264
PIN 2x10mm (10pcs)
Z282
STEP SCREW M3x14mm (4pcs)
Z420
CAP HEAD SCREW M2.6x6mm (12pcs)
Z422
CAP HEAD SCREW M2.6x10mm (12pcs)
Z423
CAP HEAD SCREW M2.6x12mm (12pcs)
Z509
BUTTON HEAD SCREW M3x30mm (6pcs)
Z517
BINDER HEAD SCREW M3x8mm (10pcs)
Z526
FLAT HEAD SCREW M3x8mm (6pcs)
Z527
FLAT HEAD SCREW M3x10mm (6pcs)
Z543
CAP HEAD SCREW M3x10mm (6pcs)
Z561
TP. FLANGED SCREW M3x10mm (6pcs)
Z567
TP. BINDER HEAD SCREW M3x10mm (10pcs)
Z568
TP. BINDER HEAD SCREW M3x12mm (10pcs)
Z569
TP. BINDER HEAD SCREW M3x15mm (10pcs)
Z578
TP. FLAT HEAD SCREW M3x12mm (10pcs)
Z581
TP. FLAT HEAD SCREW M3x18mm (10pcs)
Z593
SCREW SHAFT 3x27mm (4pcs)
Z599
SCREW SHAFT 3x40mm (4pcs)
Z653
NUT M3 (6pcs)
Z662
LOCK NUT M2 (4pcs)
Z684
FLANGED LOCK NUT M4 (4pcs)
Z694
WASHER M5x10x0.5mm (10pcs)
Z699
WASHER 7x12x0.8mm (6pcs)
Z721
SET SCREW M4x4mm (4pcs)
Z903
ALLEN WRENCH 2.5mm
Z904
ALLEN WRENCH 2.0mm
Z950
CROSS WRENCH (SMALL)
Z960
TURNBUCKLE WRENCH 4mm/5.5mm
