Parts List
Ersatzteileliste
Parts List
Parts #
Description
PRECUT FOAM BUMPER GRAY (RS4)
6274
6543
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SIL/2pcs)
6544
RACING SHOCK SPRING 14x25x1.5mm 6 COILS(GOLD/2pcs)
6820
SILICONE O-RING P-3 (CLEAR/8pcs)
SERVO SAVER SET (BODY/HONE)
61644
39 TOOTH PULLEY (ONE-WAY)
61051
61087
SOLID AXLE CUP (STEEL/2pcs)
61092
WHEEL NUT M4 SERRATED (PURPLE/4pcs)
61148
DIFF THRUST WASHER (2pcs)
DIFFERENTIAL THRUST BALL 1/16"
61149
BEARING HOLDER PARTS
61237
61246
TURNBUCKLE 3x24mm (2pcs)
61247
TURNBUCKLE 3x34mm (2pcs)
61327
CYLINDER UPPER CAP (PURPLE/2pcs)
CYLINDER LOWER CAP (PURPLE/2pcs)
61328
44mm ALUMINUM UNIVERSAL DRIVE SHAFT (PURPLE/1pc)
61338
61627
DIFF RING (2pcs)
67712
UPPER BULK HEAD SET (PURPLE)
67716
SHOCK BODY
GRAPHITE SUSPENSION ARM SET
67717
SWAY BAR HOLDER
67718
67721
39T PULLEY (PRO SPEC BALL DIFF)
67722
CERAMIC DIFF BALL (3mm/12pcs)
67725
DIFF SCREW SET (PRO SPCE BALL DIFF)
Li-PO BATTERY HOLDER SET
67841
BELT 171T
68703
68704
BELT 64T
68705
CENTER PULLEY 20T (SPUR GEAR HOLDER)
68706
CENTER PULLEY 20T
SWAY BAR SET (1.2mm/1.3mm/1.4mm)
68707
MAIN CHASSIS (2.5mm)
68710
68711
UPPER DECK (2.0mm)
68713
FRONT SHOCK TOWER
68714
REAR SHOCK TOWER
GRAPHITE BUMPER BRACE
68715
LOWER BULK HEAD (2pcs)
68716
68717
MOTOR MOUNT
68718
MIDDLE BLOCK
68721
SOLID AXLE SET
ALUMINUM WASHER 4x6x1.0mm (4pcs/PURPLE)
68723
DIFF OUTDRIVE SET (POM)
68725
68726
BALL DIFFRENTIAL SET
68727
CENTER SHAFT 4x26mm
68728
HB TCX DECAL
UNIVERSAL DRIVE SHAFT (46mm/1pc)
68734
STEERING ARM SET
68735
68739
CENTER SHAFT PIN 2x9.8mm (10pcs)
68745
HB RACING SPUR V2 GEAR 115 TOOTH (64PITCH)
68755
PIVOT BLOCK (FR/PURPLE)
PIVOT BLOCK (RF/PURPLE)
68756
CARBON GRAPHITE BLOCK AND HUB SET
73507
73510
SHOCK PARTS/BALL END SET
73513
BUMPER/BODY POST SET
73518
CARBON GRAPHITE C HUB SET (4 DEGREES)
BLADDER 12x3.5mm (FLAT TYPE/4pcs)
73523
BODY CLIP (6mm/BLACK/20pcs)
75106
75115
BALL STUD 4.3x10.3mm (2mm SOCKET/4pcs)
75116
BALL STUD 4.3x13mm (2mm SOCKET/4pcs)
75119
SUSPENSION SHAFT 2.5x24.5mm (2pcs)
PIVOT BALL 3x5mm (4pcs)
75121
STEERING BLOCK BUSHING (4pcs)
75122
75161
PIVOT BLOCK (2.5 DEGREES/ALUMINUM/PURPLE)
75162
PIVOT BLOCK (3 DEGREES/ALUMINUM/PURPLE)
75187
UNIVERSAL AXLE (2pcs)
UNIVERSAL Rebuild KIT (2pcs)
75188
SPRING 6x7x1.5mm (DIFFERENTIAL) BLACK (2pcs)
A165
A302
HEAVY-DUTY BALL CUP 4.3x18mm (8pcs)
B012
BALL BEARING 3x6x2.5mm (FLANGED/2pcs)
B017
BALL BEARING 4x8x3mm (2pcs)
BALL BEARING 5x8x2.5mm (2pcs)
B020
BALL BEARING 5x10x4mm (2pcs)
B021
B030
BALL BEARING 10x15x4mm (2pcs)
HB70712
SHAFT 3x45mm, 2pcs (CYCLONE)
HB70720
CYLINDER NUT (BLACK/2pcs)
HIGH GRADE SHOCK SHAFT, 28mm, 2pcs (CYCLONE)
HB70721
SHOCK PISTON (1.2), 2pcs (CYCLONE)
HB70722
HB70723
ROD GUIDE, 2pcs (CYCLONE)
HB70742
ALUMINUM HEX HUB SET (CLAMP TYPE/4pcs/CYCLONE)
Z082
FLAT HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
FLAT HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
Z083
Z150
ANTENNA PIPE SET
Z155
DIFFERENTIAL LUBE (SILICONE)
Z156
GRAY DIFFERENTIAL LUBE (FOR DIFF SMALL BALLS)
Z203
WASHER M3x6mm (10pcs)
BUTTON HEAD SCREW M3x15mm (HEX SOCKET/4pcs)
Z216
Z234
CAP HEAD SCREW M2x5mm (10pcs)
Z242
E CLIP E2mm (20pcs)
Z264
PIN 2x10mm SILVER (10pcs)
Z350
BUTTON HEAD SCREW M3x5mm (HEX SOCKET/10pcs)
BUTTON HEAD SCREW M3x8mm (HEX SOCKET/10pcs)
Z352
Z353
BUTTON HEAD SCREW M3x10mm (HEX SOCKET/10pcs)
Z354
BUTTON HEAD SCREW M3x12mm (HEX SOCKET/10pcs)
Z356
BUTTON HEAD SCREW M3x18mm (HEX SOCKET/10pcs)
Z653
NUT M3 (6pcs)
LOCK NUT M3 THIN TYPE (4pcs)
Z676
Z700
SET SCREW M3x3mm (6pcs)
Z724
SET SCREW M4x8mm (ROUND POINT/6pcs)
Z775
SET SCREW TP3.2x5mm
Z814
ALUMINUM WASHER 3x6x0.75mm (PURPLE/10pcs)
ALUMINUM WASHER 3x6x1.5mm (PURPLE/10pcs)
Z816
Z817
ALUMINUM WASHER 3x6x2.0mm (PURPLE/10pcs)
Z825
WASHER M4x6x0.2mm (COPPER/10pcs)
Z852
WASHER 5x7x0.2mm (10pcs)
All manuals and user guides at all-guides.com
Liste de pièces
パーツリスト
Ersatzteileliste
Nummer
Beschreibung
ANGEPASSTER RAMMER GRAU RS4
6274
6543
DAEMPFERFEDER RACING 14x25x1.5mm 6.5WDG. (SIL/2ST)
6544
DAEMPFERFEDER RACING 14x25x1.5mm 6WDG. (GOLD/2ST)
6820
SILIKON O-RING P-3 (TRANSPARENT/8 ST.)
SERVO SAVER SET (CYCLONE 12)
61644
RIEMENRAD 39Z (FREILAUF) CYCLONE
61051
61087
CUP JOINT F. STARRACHSE (STAHL/2ST/CYCONE)
61092
RADMUTTER M4 (GERIFFELT/LILA/4ST)
61148
DRUCKLAGERSCHEIBEN 2.8x5.8x1mm (2ST)
DRUCKLAGERKUGELN 1/16
61149
LAGERHALTER TEILE (CYCLONE S)
61237
61246
SPURSTANGE 3x24mm (2 ST/CYCLONE S)
61247
SPURSTANGE 3x34mm (2 ST/CYCLONE S)
61327
DAEMPFERKAPPE OBEN (LILA/2 ST) CYCLONE
DAEMPFERKAPPE UNTEN (LILA) CYCLONE
61328
ALUMINIUM KARDAN 44MM (LILA/1 ST) CYCLONE
61338
61627
DIFFERENTIAL-RINGE (2ST/CYCLONE 12)
67712
OBERES DIFFGEHAEUSE SET (LILA/CYCLONE TC)
67716
DAEMPFERGEHAEUSE (2ST/CYCLONE TC)
SCHWINGEN SET (KOHLEFASERVERSTAERKT/CYCLONE TC)
67717
STABILISATOR HALTER
67718
67721
RIEMENRAD 39Z (PRO SPEC DIFF)
67722
KERAMIK DIFFERENTIALKUGELN (3mm/12ST)
67725
DIFFERENTIAL SCHRAUBE M2.6x31mm (PRO SPEC DIFF)
LIPO AKKUHALTER SET (TCX)
67841
RIEMEN 171Z (TCX)
68703
68704
RIEMEN 64Z (TCX)
68705
RIEMENRAD 20Z/HAUPTZAHNRADHALTER (TCX)
68706
RIEMENRAD 20Z (TCX)
STABILISATOR SET (1.2mm/1.3mm/1.4mm/TCX)
68707
CHASSIS (2.5mm/TCX)
68710
68711
OBERDECK (2.0mm/TCX)
68713
DAEMPFERBRUECKE VORNE (TCX)
68714
DAEMPFERBRUECKE HINTEN (TCX)
RAMMER-STREBE KOHLEFASER (TCX)
68715
UNTERER BULKHEAD (1ST/TCX)
68716
68717
MOTORHALTER (TCX)
68718
MITTELBLOCK (TCX)
68721
STARRACHSEN SET (TCX)
ALUMINIUM SCHEIBE 4x6x1.0mm (4ST/LILA)
68723
DIFF ABTRIEB SET (POM/TCX)
68725
68726
KUGELDIFFERENTIAL SET (TCX)
68727
MITTELWELLE 4x26mm (TCX)
68728
HB TCX AUFKLEBER
KARDANKNOCHEN (46mm/1ST/TCX)
68734
LENKHEBEL SET (TCX)
68735
68739
MITTELWELLEN STIFT 2x9.8mm (10ST/TCX)
68745
RACING HAUPTZAHNRAD V2 115 ZAEHNE (64DP)
68755
QUERLENKERHALTER V/H (ALUMINIUM/LILA)
QUERLENKERHALTER H/V (ALUMINIUM/LILA)
68756
LENKHEBEL/TRAEGER (KOHLEFASERVERSTAERKT)
73507
73510
DAEMPFERTEILE/KUGELKOPF SET
73513
RAMMER/KAROSSERIEHALTER SET
73518
LENKHEBELTRAEGER (4 GRAD/KOHLEFASERV.)
DAEMPFERMEMBRAN 12x3.5mm (FLACH/4 ST)
73523
KAROSSERIEKLAMMERN (6mm/SCHWARZ/20ST)
75106
75115
KUGELKOPF 4.3X10.3mm (2mm INBUS/4ST)
75116
KUGELKOPF 4.3x13mm (2mm INBUS/4ST)
75119
ACHSSTIFTE 2.5x24.5mm (2ST)
KUGELKOPF 3x5mm (4ST)
75121
LENKUNGSLAGER (4ST)
75122
75161
QUERLENKERHALTER (2.5 GRAD/ALU/LILA)
75162
QUERLENKERHALTER (3 GRAD/ALU/LILA)
75187
KARDAN ACHSE (2ST/PRO4/CYCLONE)
KARDAN WARTUNGS SET (2ST/PRO4/CYCLONE)
75188
DIFF-FEDER 6x7x1.5mm SCHWARZ (2 ST.)
A165
A302
KUGELPFANNE 4.3x18mm (8 ST.)
B012
KUGELLAGER 3x6x2.5mm (MIT FLANSCH/2ST)
B017
COMPETITION LOW FRICTION KUGELLAGER 4x8x3mm 2 ST.
COMPETITION LOW FRICTION KUGELLAGER 5x8x2.5mm 2 ST
B020
COMPETITION LOW FRICTION KUGELLAGER 5x10mm (2 ST.)
B021
B030
COMPETITION LOW FRICTION KUGELLAGER 10x15x4mm 2 ST
HB70712
ACHSSTIFT 3x44.5mm (2ST/CYCLONE)
HB70720
DAEMPFER EINSTELLMUTTER (SCHWARZ/2ST/CYCLONE)
KOLBENSTANGE HIGH GRADE 28mm (2ST/CYCLONE)
HB70721
KOLBENPLATTEN (2L/1.2mm/2ST/CYCLONe)
HB70722
HB70723
KOLBENSTANGENFUEHRUNG (2ST/CYCLONE)
HB70742
ALU FELGENMITNEHMER ZUM KLEMMEN (CYCLONE)
Z082
SENKKOPFSCHRAUBE M3x8mm (INBUS/10ST)
SENKKOPFSCHRAUBE M3x10mm (INBUS/10ST)
Z083
Z150
ANTENNENROHRSET
Z155
DIFFERENTIAL FETT
Z156
GRAUES DIFFERENTIALFETT
Z203
M3X6 UNTERLAGSCHEIBE (10 ST.)
FLACHKOPFSCHRAUBE M3x15mm (INBUS/4ST)
Z216
Z234
INBUSSCHRAUBE M2x5mm (10ST)
Z242
E-CLIP E2mm SILBER 20ST.
Z264
STIFT 2x10mm SILBER (10 ST.)
Z350
FLACHKOPFSCHRAUBE M3x5mm (INBUS/10ST)
FLACHKOPFSCHRAUBE M3x8mm (INBUS/10ST)
Z352
Z353
FLACHKOPFSCHRAUBE M3x10mm (INBUS/10ST)
Z354
FLACHKOPFSCHRAUBE M3x12mm (INBUS/10ST)
Z356
FLACHKOPFSCHRAUBE M3x18mm (INBUS/10ST)
Z653
MUTTER M3 6ST.
STOPPMUTTER M3 (FLACH)
Z676
Z700
MADENSCHRAUBE M3x3mm (6ST)
Z724
MADENSCHRAUBE M4x8mm (6ST)
Z775
MADENSCHRAUBE TP3.2x5mm
Z814
ALUMINIUM UNTERLAGSCHEIBE 3x6x0.75mm (LILA/10 ST.)
ALUMINIUM UNTERLAGSCHEIBE 3x6x1.5mm (LILA/10 ST.)
Z816
Z817
ALUMINIUM UNTERLAGSCHEIBE 3x6x2.0mm (LILA/10 ST.)
Z825
UNTERLAGSCHEIBE M4x6x0.2mm (KUPFER/10 ST.)
Z852
UNTERLAGSCHEIBE 5x7x0.2mm (10ST.)
40
