COMMAND MANAGEMENT FROM WHITE OR BLACK WIRE
NB: The motors are factory set to be used with one button (UP-STOP-DOWN-STOP
operation). The operating mode setting can be modified by following the sequence
indicated below.
SETTING THE OPERATING MODE:
Tn: Memorised remote control
+
B C
Tn
There are 3 possible settings available in the order indicated below:
- UP-STOP-DOWN-STOP (factory setting)
- UP-DOWN (for 2 independent buttons)
- UP-DOWN in "dead-man" mode (for 2 independent buttons)
To switch from one setting to another, repeat the sequence as many times as neces-
sary to reach the required setting.
Active mode UP-STOP-DOWN-STOP:
B C
Active mode UP-DOWN:
B C
Active mode UP-DOWN in "dead-man" mode:
B C
TM2 R
B
Tn
B
B
B
34
C
Tn (2 sec)
C
C
C
