Specifications
CE - Mark
ETL sign:
Country of origin:
Pump:
Stirring speed:
Hoses:
Connections
Power supply (top);:
Housing
Material:
Dimensions:
Weight:
Ambient conditions:
Climate:
Titration Stand TM 235 KF
In connection with the titrator TitroLine 7500 KF
EMV – compatibility according to Council Directive 89/336/EWG;
Transient emissions according to norm EN 50 081, part 1
Interference resistance according to norm EN 50 082, part 2
Low voltage directive according to Council Directive 73/23/EWG
Last amended by directive 93/68/EWG; test criteria EN 61 010, part 1
Conforms to ANSI/ UL Std. IEC 61010-1
Certified to CAN/ CSA Std. C22.2 No. 61010-1
Germany / made in Germany
Free volume flow - air-:
Delivery pressure max.
Flow rate liquid medium
50 ... 1000 U/min
PVC- hose, outer diameter 6 x 1 mm
PTFE- hose, outer diameter 4 x 0.5 mm
Low voltage input 12 V / − on the backside of titration stand
Plug connection: plug for low voltage connection – phone jack-,
Positive pole at pin contact, inside contact ∅ = 2,1 mm, USA/Japan,
Power supply via titrator TitroLine 7500 KF
Use the Power supply TZ 1855, Type No.: FW 7555O/12 only!
Polypropylene;
80 x 130 x 250 mm, H x W x D (height without stand rod)
1.0 kg
Not suitable for explosive environments!
Ambient temperature:
Humidity:
flow rate 2.25 l / min
1.5 bar
ca. 0,8 l / min
+ 10 °C ... + 40 °C for storage and transport.
According to EN 61 010, part 1:
Maximum relative humidity 80 % for temperatures up to
31 °C,
Linearly decreasing up to 50 % relative humidity
With a temperature of 40 °C
Status Nov 21. 2013
