tween the spoke magnet and the marking position
on the speed sensor is 1 to 5 mm . If the distance
is different, an error message will appear.
Power supply to external devices
You can use the USB port to charge external de-
vices, e .g . smartphones, that can be powered via
USB . The charging cable of the device can be
connected directly to the FLYER display .
In order to charge external devices, your FLYER
e-bike must contain a charged FLYER battery.
Open the cover of the USB port on the display
and connect the charging cable to it .
• Do not place the connected device
on a tilted or unstable place while
charging . Otherwise, it could fall and
become damaged .
• Do not charge external devices in
rainy weather or connect a wet USB
cable . The USB connection is not wa-
terproof!
• You must not connect external de-
vices when riding in the rain and the
USB port must be completely covered
by the protective cap .
• After using the USB port, be sure to
firmly tighten the rubber cap.
• Make sure that the voltage of the USB
port is suitable for your device . (See
the technical data for the voltages)

5.9 Battery

Check the battery before you charge it
for the first time or use it in your FLYER
e-bike.
Completely charge the battery using
the charger before the first ride to
ensure full battery performance . Read
and adhere to the operating instructions
for the charger when charging the bat-
tery .
Charging status indicator
Batterie FIB-810
23
The main menu "Drive" on your display contains
a symbol that indicates the battery charge level,
which is also shown as a percentage . In all other
menus, the charge level is displayed as a symbol
in the top-left. If the charge level is less than 20%,
the battery is red .
Battery charge level check
1 LED battery charge indicator
Shows the e-bike battery's remaining capacity.
If an error occurs, an error code is displayed (see
Chapter 5 .10 Battery error codes)
2 Control button for battery charge level
Let the LED battery charge level indicator blink to
verify the remaining battery capacity .
3 Charger connector
4 Rubber cap
Protects the charger connectors when the battery
is not being charged .
To check if the battery is charging, press the control
button on the battery to be shown the charge level .
Charge the battery when not all of the five charge
indicator LEDs light up . Only use the original
charger .
Never use chargers supplied by other manufac-
turers! A fast-flashing LED indicates that the bat-
tery has been completely discharged .
EN
