upper and lower thrust bearings be adjusted equally.
■ Open the front covers and blade guard.
■ Using a hex key, loosen the upper and lower thrust
bearing screws and push thrust bearings to the back
of the saw.
■ Verify that saw blade is tracking correctly, then slide
the thrust bearing forward until the bearing is within
0.4 mm (1/64") of the blade. Tighten the thrust bearing
screw securely.
■ Slide lower bearing forward until it has proper
clearance. Tighten the thrust bearing screw securely.
to adjust blade guide support:
■ Loosen the blade guide support and blade guide set
screws using hex keys.
■ Slide the upper blade guide support on the shaft until
the front edge of the guides contact the saw blade
behind the gullet. Tighten the screw securely.
■ Push the right guide to contact the blade and release.
Slowly rotate wheel one full rotation. Tighten blade
guide set screws.
■ Adjust left side guide to allow 0.4 mm (1/64") clearance
between the blade and guide (about the thickness of a
playing card) by inserting a playing card between left
guide and blade.
■ Apply pressure to left guide pin to hold the playing card
in place. Tighten set screw and remove the playing
card.
■ Rotate, by hand, a full three rotations to make sure
blade will not bind.
■ Close the blade guard and front cover. Lock with
screw.
Repeat this procedure for the lower blade guide support.

aDJustinG tHE rip fEncE

■ Loosen the lock handle by turning it counterclockwise.
■ Move the rip fence to the desired position.
■ Push down the lock handle to lock the position of the
rip fence.
■ Turn the lock handle to adjust tightness of the clamps.
MaintEnancE
warninG
When servicing, use only identical replacement parts.
Use of any other parts can create a hazard or cause
product damage.
PT DA SV FI NO RU
English
PL CS HU RO LV LT
Always wear eye protection during product operation. If
operation is dusty, also wear a dust mask.
Before performing any maintenance, make sure the tool
is unplugged from the power supply and the switch is in
the off position. Failure to heed this warning could result
in serious personal injury.

GEnEral MaintEnancE

Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
injury.
■ Keep your band saw clean.
■ Remove sawdust from the inside frequently.
■ Do not allow pitch to accumulate on the saw table,
blade guides, or thrust bearings. Clean them with gum
and pitch remover.
■ Apply a thin coat of automobile type wax to the saw
table's top so the wood slides easily while cutting.

lubrication

All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit
under normal operating conditions. Therefore, no further
lubrication is required.
tirEs
cleaning tires:
■ Pitch and sawdust accumulates on tires and needs to
be removed with a fine wire brush or a piece of wood.
Do not use a sharp knife or any kind of solvent.
replacing tires:
■ Open front cover and remove saw blade. See section
on installing and adjusting the Blade.
■ Pry the worn tire away from the wheel carefully.
■ Stretch the new tire around the wheel.
11
