SETTING UP THE INSTRUMENT

In order to enter the system main menu Keep the "ENTER" button pressed down for 3 seconds until the backlit LCD
display starts to blink.
Release the "ENTER" button.
p
q
Use the
and
buttons (UP and DOWN) to scroll the functions through the main menu.
The current function selection is the one that appears between the symbols
Main menu entrance
screenful
The programmable functions in the system's main menu are:
DATA ITEM
SYNTHETIC DESCRIPTION
BATTERY TYPE
Allows the settings of the type of batteries to be charged.
MONITOR MODE
Allows enabling or disabling the monitor mode.
FLOAT THRESHO
Allows the setting of the FLOAT threshold.
MAX CURRENT
Allows the setting of the maximum output currenty.
SILENT MODE
Allows to enable or disable the silent mode.
RESET
It allows the reset of the battery charger.
CONFIG RDS
It allows to set the parameters of the RDS 1560 remote panel.
EXIT
Exiting from menu.
THE STRUCTURE OF THE MENU
BATTERY TYPE
MONITOR MODE
FLOAT THRESHO
MAX CURRENT
SILENT MODE
RESET
CONFIG RDS
EXIT
RDS 1560 - REV001A
B A T T E R Y T Y P E
u
M o n i t o r m o d e
Open Liquid
Sealed Liquid
Gel
AGM
Disable
Enable
5%
10%
15%
20%
25%
30%
100%
90%
80%
70%
60%
50%
Disable
Enable
No
Yes
Language
CAN group
CAN Priority
Beep alert
Backlight
LCD contrast
Key beep
Exit
OPERATION - SETTING UP
u
t
and
The symbols
t
scrolling direction (UP and DOWN) for
the functions' selection in the main
q
menu.
English
Italiano
Francais
Espanol
Deutsch
Group A
Group B
Group C
Priority 1
Priority 2
Priority 3
On warnings
On errors
Exit
10%
30%
50%
70%
90%
100%
1
2
3
4
5
Disable
Enable
.
p
q
and
indicate the
Disable
Enable
Disable
Enable
GB
19
