PROGRAMMING (PH)

Through the front panel it is possible to set and to modify all the working parameters of operating setting of the pump.

Pu m p S et u p

The pump goes in measure mode, on display
will show the measure's value.
Press OK button to enter in menus; the first is
SETPOINT menu, using + and - buttons you will
scroll all 3 menus.

S ET PO INT se t t in g

To have the pump operative it's mandatory set the following data: Setpoint values, type of dosing, manual or proportional
dosing and flow rate percentage.

S ET PO INT va lu e

From measuring status, pressing OK, the pump will
go in SETPOINT programming phase. Setpoint icon
will flash. Pressing OK again, the setpoint value
saved will flash and can be adjusted using + and -
buttons.
Pressing OK, the setpoint value will be memorized.
The pump automatically will go in DIRECTION
menu
ENGLISH
78
Setpoint Menu
Calibration Menu
Alarms Menu
