M ain f eat u r es
Max.
Max. Pressure
Flow
Type
l/h
2-5
2
5-7
5
10-5
10
20-3
20
The diagrams of fig. 3 indicate max metering pump flow variation in relation to the working pressure in the plant; the
diagrams also include injection valve losses. I.V.P.
Due to production requirements the technical characteristics of our equipment at maximum ratings can vary with a
tolerance of 5% which must be taken into account when choosing the type of pump.
In st a llat io n
A) Install the pump in a dry place and well away from sources of heat and, in any case, at environmental temperatures
not exceeding 40°C. The minimum operating temperature depends on the liquid to be pumped, bearing in mind that it must
always remain in a liquid state.
B) Carefully observe the regulations in force in the various countries as regards electrical installations (Fig.4).
When the supply cable is devoid of a plug, the equipment should be connected to the supply mains by means of
a single-pole circuit breaker having a minimum distance of 3 mm between the contacts. Before accessing any of the
electrical parts, make sure that all the supply circuits are open.
Output per
stroke
Max imp./mín.
bar
5
120
0,28
7
120
0,70
5
120
1,40
3
120
2,77
5/7
2/5
Suction
Stroke
height
mm
ml
m
0,60
2
1,00
2
1,15
2
1,80
2
Fig. 2
10/5
Fig. 3
Standard power
Power
supply
cons.
Watts
Volts/Hz
230 V 50 - 60 Hz
22
230 V 50 - 60 Hz
22
230 V 50 - 60 Hz
50
230 V 50 - 60 Hz
111
20/3
Fig. 4
Current
Net
cons.
weight
Ampere
kg
0,11
3,5
0,11
3,5
0,25
4,2
0,51
4,2
