OPERATION
GB

SETTING UP THE INSTRUMENT

The instrument is set up using a Dip-Switch. To configure the unit, priority of the battery charger which the information
is shown for and CAN termination, refer to the table given below:
SWITCH 1 SWITCH 2
OFF
OFF
ON
SWITCH 3 SWITCH 4
OFF
OFF
ON
SWITCH 5
OFF
ON
SWITCH 6
OFF
ON
SWITCH 7 SWITCH 8
OFF
OFF
ON
ON
FACTORY SETTING:
16
FUNCTION
OFF A
GROUP
ON B
GROUP
OFF C
GROUP
FUNCTION
OFF 1
PRIORITY
ON 2
PRIORITY
OFF 3
PRIORITY
FUNCTION
CAN TERMINATOR DEACTIVATED
CAN TERMINATOR ACTIVATED
FUNCTION
Backlighting Intensity LOW
Backlighting Intensity HIGH
FUNCTION
OFF
Voltage display MASTER
ON
Voltage display MASTER, SLAVE 1
OFF
Voltage display MASTER, SLAVE 2
ON
Voltage display MASTER, SLAVE 1 / 2
A
GROUP
1
PRIORITY
CAN TERMINATOR DEACTIVATED
Backlighting Intensity LOW
Voltage display MASTER
DESCRIPION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
DESCRIPION
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
RDS 1541 - REV001A
