Below is an example of a CAN BUS network connection with 2 or 3 networking battery chargers:
SBC NRG
CAN IN
2
1
8
8
1
1
TERMINATION
CONNECTOR
CAN OUT
SBC NRG
CAN IN
2
1
8
8
1
1
TERMINATION
CAN OUT
CONNECTOR

ACTIVATING THE TERMINATORS

Activate the termination at the first and last device connected to the network.
To activate the termination, see paragraph SETTING UP THE INSTRUMENT.
