RDV-1080 DVD Audio/Video Player
tions. When only one identifier appears, that
control is available only on the front-panel or
the remote, but not both.
The DVD functions available on the remote are
detailed in the sections of this manual describing
operation of the RDV-1080.

Setting the TV code

To use the RR-DV93 with your TV, you need
to program the command set for your TV by
entering a 2-digit code from the list in Figure
3. This need only be done once.
Find your TV brand in the code list and note
the 2-digit code(s):
1. Press and hold the TV/VIDEO button
keeping it pressed during Steps 2 and 3
below.
2. Enter the 2-digit code using the NUMERIC
keypad . For example, to enter code 01,
press 0, then 1.
3. Press the STOP button
selected code.
4. Release the TV/VIDEO button and test the
new code by pressing the TV POWER
button . If the TV turns on and off, you
have programmed the correct code.
5. If the programmed code does not turn the
TV on or off, try a different code for the
brand of TV.

TV Functions

The following TV control functions are avail-
able on the RR-DV93 remote whenever the TV/
DVD switch is in the TV position:
TV POWER : Turns the TV on or off.
TV/VIDEO : Switches between the TV an-
tenna input and the video input on the TV set.
CH : Changes the TV channel.
VOL : Changes the TV volume.
MUTE/+10 : Mutes the TV sound.

On-Screen Displays

The RDV-1080 displays a number interactive
screens on the TV monitor during normal op-
eration. Many of these screens are used to
set up preferences and activate advanced fea-
tures of the unit. These are described in de-
tail later in this manual.
This section gives an overview of the types of
On-Screen Displays which may appear and
a general guide to using them.
: The default language for all RDV-1080
NOTE
On-Screen Displays can be changed. See the
Setting Preferences section of this manual.

Opening Screens

When the RDV-1080 is turned on, an Open-
ing Screen display generally appears on your
TV. For example, if no disc is inserted in the
player, the following screen appears with an
icon indicating that a disc needs to be inserted:
,
to store the
If a disc is inserted, the opening screen will
show a different icon indicating type of disc
(DVD Video, DVD Audio, Audio CD, etc.)
Display Screens
ON SCREEN Button
A number of menu screens can appear dur-
ing setup and operation of the RDV-1080 such
as the sample below:
These screens provide access to a range of
settings and features. They appear automati-
cally when certain remote control buttons are
pressed. In addition, they can be manually
activated by pressing the ON SCREEN but-
ton on the remote.
The On-Screen Displays are context-sensitive
– the specific screen depends on what kind
of disc is inserted and what the unit is doing.
For example, if you press the ON SCREEN
button with no disc inserted, a PREFERENCES/
SPEAKER SETUP screen is displayed allowing
you to make general settings. If you press the
14
ON SCREEN button while a DVD Video disc
is inserted, the screen provides options and
features related to playing DVD Video discs.
Details of these screens appear throughout this
manual.

Using On-Screen Displays

CURSOR Buttons

ENTER Button

NUMERIC Buttons

To operate any of the On-Screen Displays, you
move the over the item on the screen you
wish to adjust and then use keys on the re-
mote to change the item:
• Move the using the CURSOR
buttons on the remote to select a setting.
Instructions for the setting appear in the
message box at the bottom of the screen.
• When a setting like
crease or decrease the setting or step
through the available options by pressing
the CURSOR
• Activate an option like
ing it and pressing the ENTER button on
the remote.
• Enter numbers on a screen by using the
NUMERIC buttons on the remote.
• Some functions take effect by pressing the
ENTER button after specifying a setting.
• Press the ON SCREEN button to turn off
the On-Screen display.

Screen Saver

To prevent damage to a TV monitor during
prolonged display of a static image, the unit
automatically activates screen saver display
after several minutes.
The screen saver display is turned off,
returning to the previous display, when any
front-panel or remote button is pressed.
: Several screen saver modes can be set
NOTE
as described in Setting Preferences.
is selected, in-
buttons on the remote.
by select-
