Parts List
En
Refer to page 38 39 for parts contents.
Part # Qty
Discription
30004
4
SHOCK SPRING ADJUST NUT (PURPLE)
50432
5
O-RING S-12 (BLACK)
6151
1
SILICONE SHOCK OIL #500
6163
5
SERVO TAPE 20x100mm
6273
8
FOAM SPACER FOR FOAM BUMPER
6274
1
PRECUT FOAM BUMPER GRAY
6542
2
RACING SHOCK SPRING 14x25x1.4mm 6 COILS (BLUE)
6543
2
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SILER)
6544
2
RACING SHOCK SPRING 14x25x1.5mm 6 COILS(GOLD)
6545
2
RACING SHOCK SPRING 14x25x1.5mm 5.75 COILS (WHITE)
6546
2
RACING SHOCK SPRING 14x25x1.5mm 5.5 COILS (YELLOW)
6547
2
RACING SHOCK SPRING 14x25x1.5mmx5.25 (RED)
6548
2
RACING SHOCK SPRING 14x25x1.5mmx6.25 (PINK)
6820
8
SILICONE O-RING P-3 (CLEAR)
6871
2
SHOCK SHAFT 3x28mm
72013
1
MIP CVD REBUILD KIT
72015
1
THREAD LOCK (MIP)
72044
1
THIN ALUMINUM HEX HUB (PURPLE)
72063
6
CONE WASHER 3.0mm/4-40 FLATHEAD (PURPLE)
72105
1
DIFF RING D CUT TYPE
72111
10
SHIM SET 3x5mm (M3x5x0.1-0.2-0.3mm)
72302
1
BALL SET FOR SWAY BAR
72446
4
BALL 3x4.7x6mm
73079
1
FRONT SHOCK TOWER
73080
1
REAR SHOCK TOWER
73081
1
STEERING PLATE
73109
1
UPPER DECK 2.25mm
73501
1
BEVEL GEAR SET (39T/16T/SPACER)
73506
1
CARBON GRAPHITE SUSPENSION ARM SET
73507
1
CARBON GRAPHITE BLOCK AND HUB SET
73508
1
STEERING PARTS SET
73510
1
SHOCK PARTS/BALL END SET
73511
1
CARBON GRAPHITE GEARBOX SET
73512
1
BRACE/BATTERY MOUNT/GAUGE SET
73513
1
BUMPER/BODY POST SET
73514
1
CARBON GRAPHITE OUTDRIVE/DRIVE CUP SET
73516
1
CARBON GRAPHITE C HUB SET (0 DEGREES)
73517
1
CARBON GRAPHITE C HUB SET (2 DEGREES)
73518
1
CARBON GRAPHITE C HUB SET (4 DEGREES)
73519
1
CARBON GRAPHITE C HUB SET (6 DEGREES)
73522
1
DIFFERENTIAL SCREW AND HEAVY-DUTY NUT SET
73523
4
BLADDER 12x3.5mm (FLAT TYPE)
73524
4
MACHINED SHOCK PISTON (1.1mm 3 HOLES)
73825
1
MAIN CHASSIS 2.5mm
75100
1
FOAM RING 1.5x9x3mm
75105
1
ALUMINUM MAIN DRIVE SHAFT 6.3x163mm (PURPLE)
75106
20
BODY CLIP (6mm/BLACK)
75108
1
INPUT SHAFT RETAINER (PURPLE)
75109
2
INPUT SHAFT SPACER (PURPLE)
75111
2
CUP JOINT 6mm
75112
2
STEERING POST 4x33.5mm
75115
4
BALL STUD 4.3x10.3mm (2mm SOCKET)
75116
4
BALL STUD 4.3x13mm (2mm SOCKET)
75119
2
SUSPENSION SHAFT 2.5x24.5mm
75120
2
SUSPENSION SHAFT 3x41mm
75121
4
PIVOT BALL 3x5mm
75122
4
STEERING BLOCK BUSHING
75125
2
SWAY BAR 1.2mm (COPPER)
75126
2
SWAY BAR 1.4mm (SILVER)
75127
2
SWAY BAR 1.6mm (BLACK)
75135
2
DIFF OUTDRIVE RING
75140
1
FRONT ONE-WAY DIFFERENTIAL 39TOOTH
75143
1
SERVO SAVER SET
75144
1
PIVOT BLOCK SPACER SET
75151
1
PIVOT BLOCK F/R (PURPLE)
75156
1
PIVOT BLOCK 0 DEGREES (PURPLE)
75158
1
PIVOT BLOCK 1 DEGREES (PURPLE)
75159
1
PIVOT BLOCK 1.5 DEGREES (PURPLE)
75160
1
PIVOT BLOCK 2 DEGREES (PURPLE)
75161
1
PIVOT BLOCK 2.5 DEGREES (PURPLE)
75162
1
PIVOT BLOCK 3 DEGREES (PURPLE)
75167
1
ALUMINUM SERVO MOUNT 10mm (PURPLE)
75168
1
FRONT SOLID AXLE SET (SPOOL)
75169
1
DELRIN OUTDRIVE SET
75179
1
ALUMINUM INPUT SHAFT SET (FRONT AND REAR/PURPLE)
75190
1
ONE-WAY GEAR BRACE (PURPLE)
75192
1
ALUMINUM MOTOR MOUNT (PURPLE)
75194
2
COMPETITION ALUMINUM THREADED SHOCK SET (46-56)
75196
2
ALUMINUM THREADED SHOCK BODY (46-56mm)
75197
2
SHOCK CAP 15x5.5mm (PURPLE)
75198
2
SHOCK CAP BOTTOM 11x5mm (PURPLE)
75199
2
SHOCK RETAINER SET
Part # Qty
Discription
76598
1
SPUR GEAR 98 TOOTH (DELRIN/64PITCH)
80824
2
MIP CVD AXLE
80827
2
MIP CVDS (PURPLE)
80828
1
MIP CVD BONE 6x46mm (PURPLE)
93462
2
TITANIUM TURNBUCKLE M3x24mm (PURPLE)
93464
2
TITANIUM TURNBUCKLE M3x29mm (PURPLE)
94036
10
BUTTON HEAD SCREW M2x5mm
A046
4
O-RING P3 BLACK
A150
12
BALL 2mm
A157
12
CARBIDE DIFFERENTIAL BALLS (3/32 in./2.4mm)
A162
2
DIFFERENTIAL SCREW M2x25mm
A165
2
SPRING 6x7x1.5mm BLACK
A166
2
DIFF THRUST WASHER 2.2x6mm
A301
8
HEAVY-DUTY BALL CUP 4.3x13mm
A302
8
HEAVY-DUTY BALL CUP 4.3x18mm
B012
2
BALL BEARING 3x6x2.5mm (FLANGED)
B015
2
BALL BEARING 4x7x2.5mm
B020
2
BALL BEARING 5x8x2.5mm
B021
2
BALL BEARING 5x10x4mm
B030
2
BALL BEARING 10x15x4mm
Z082
10
FLAT HEAD SCREW M3x8mm (HEX SOCKET)
Z083
10
FLAT HEAD SCREW M3x10mm (HEX SOCKET)
Z087
10
FLAT HEAD SCREW M3x20mm (HEX SOCKET)
Z150
1
ANTENNA PIPE SET
Z155
1
DIFFERENTIAL LUBE
Z156
1
GRAY DIFFERENTIAL LUBE
Z159
1
THREAD LOCK
Z164
1
HEAVY WEIGHT GREASE
Z203
10
WASHER M3x6mm
Z216
4
BUTTON HEAD HEX SOCKET SCREW M3x15mm
Z234
10
CAP HEAD SCREW M2x5mm
Z242
20
E CLIP E2mm
Z264
10
PIN 2x10mm SILVER
Z273
12
PIN 1.6x8mm
Z305
4
SCREW POST M3x15mm
Z350
10
BUTTON HEAD SCREW M3x5mm (HEX SOCKET)
Z352
10
BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
Z353
10
BUTTON HEAD SCREW M3x10mm (HEX SOCKET)
Z354
10
BUTTON HEAD SCREW M3x12mm (HEX SOCKET)
Z356
10
BUTTON HEAD SCREW M3x18mm (HEX SOCKET)
Z438
10
BINDER HEAD SCREW M2x4mm
Z541
6
CAP HEAD SCREW M3x6mm
Z653
6
NUT M3
Z675
5
ALUMINUM THIN LOCK NUT M3 (PURPLE)
Z679
5
WHEEL NUT M4 (PURPLE)
Z700
6
SET SCREW M3x3mm
Z705
6
SET SCREW M3x10mm
Z724
6
SET SCREW M4x8mm (ROUND POINT)
Z775
6
SET SCREW TP3.2x5mm
Z814
10
ALUMINUM WASHER 3x6x0.75mm (PURPLE)
Z817
10
ALUMINUM WASHER 3x6x2.0mm (PURPLE)
Z819
10
ALUMINUM WASHER 3x6x3.0mm (PURPLE)
Z852
10
WASHER 5x7x0.2mm
Z891
10
WASHER 10x12x0.1mm (COPPER)
Z892
10
WASHER 10x12x0.2mm
Z901
1
ALLEN WRENCH 1.5mm
Z903
1
ALLEN WRENCH 2.5mm
Z904
1
ALLEN WRENCH 2.0mm
Z950
1
CROSS WRENCH
Z960
1
TURNBUCKLE WRENCH
Optional Parts
Part # Qty
Discription
73085
1
GRAPHITE CAMBER PLATE
73825
1
MAIN CHASSIS 2.5mm
73826
1
MAIN CHASSIS 3.0mm
75053
12
CERAMIC NITRIDE DIFFERENTIAL BALL (2.4mm)
75165
1
CHASSIS WEIGHT SET
75170
1
HEATSINK MOTOR PLATE (PURPLE)
75172
8
DELRIN PIVOT BALL 3x5mm
75174
8
DELRIN BEARING ADAPTER (from 5x10x4 to 5x8x2.5)
75175
1
PRO 4 SPRING SET (ID14mmxL25mm)
Z046
2
TITANIUM MOTOR SCREW M3x6mm (PURPLE)
73086
1
GRAPHITE BUMPER BRACE
34
