Parts List
Ersatzteilliste
Parts List
En
Parts # Qty Description
341
1
SC-15 Electronic Speed Control With Reverse
1146
1
FIREBOLT 15T Motor (540 Type)
3835
2
TE 37 Wheel White 26mm (0mm Offset)
3840
2
TE 37 Wheel White 26mm (3mm Offset)
3842
2
TE 37 Wheel Chrome 26mm (3mm Offset)
3847
2
TE 37 Wheel Chrome 26mm (6mm Offset)
4790
2
X-pattern Radial Tire 26mm D-compound
6122
10
Body Pin (Medium)
6274
1
Precut Foam Bumper Gray (RS4)
6807
2
Shock Shaft 3x31mm
6816
6
Silicone O-ring S10
6819
5
Silicone O-ring P-3 (Red)
6831
2
Shock Spring 13x25x1.7mm 7 Coils (Black)
6928
1
Pinion Gear 28 Tooth (48 Pitch)
6987
1
Spur Gear 87 Tooth (48 Pitch/carbon Fiber)
72102
2
Shock Cap 12xm13x0.8mm (Purple/ Grooved)
80550
1
HPI TF-1 (AM) Transmitter
80556
1
HPI RF-1 Receiver
80559
1
HPI SF-1 Servo
85000
1
Suspension Arms
85001
1
Bulkhead
85003
1
Wheel Adapter (ax4, Z264x4, Z684x4)
Bumper (ax1, bx1)
85009
1
85010
1
Battery Holder Set
Pulley Set (ax2, bx2, Z262x2 )
85016
1
Suspension Pin Set (ax4, bx4)
85021
1
85022
1
Gear Diff Case (ax1,bx1)
85087
1
Main Chassis
85088
1
Upper Deck
85090
1
Shock Tower/body Post Set
85092
1
Front C Hub (4 And 6 Degrees)/knuckle Arm Set
85095
1
Rear Hub Set (2 And 3 Degrees)
85097
1
Center Post/servo Horn/steering Crank Set
86001
2
Middle Lay Shaft 4x61mm
86003
1
Spur Gear Mount (ax1,bx1)
86004
1
Steering Flange Pipe
86009
1
Suspension Pin Brace
86010
1
Motor Plate Set (ax1,bx1,cx1,dx1,ex1)
86011
1
Gear Diff Bevel Gears (ax2,bx2,cx2)
86014
1
Gear Diff Shaft (ax1,bx1)
86015
1
Front Belt Tensioner (ax1,bx1, B070x2, Z244x1, Z517x1, Z694x1)
86041
1
Servo Saver Shaft 4x31mm
86190
1
Ball 4.3x20mm (4-40/black)
86191
4
Dogbone 6x41mm
86193
2
Ball 4.3x4mm (4-40)
86195
4
Ball 4.3x11.5mm (4-40/hex Socket/silver)
86196
4
Urethane Belt S3m 507 Ug 4mm (Front)
87006
1
Urethane Belt S3m 174 Ug 4mm (Rear)
87007
1
Turnbuckle 4-40x24mm
93312
2
Turnbuckle 4-40x34mm
93317
2
Servo Saver Pipe
A181
1
Servo Saver Nut Set (With Spring)
A182
1
Pilot Shaft 4x15mm
A183
2
Steering Joint Set
A185
1
Shock Parts Set
A471
2
HPI Sports Shock Body (45-56mm)
A540
2
Ball Bearing 4x8x3mm
B017
2
Ball Bearing 5x10x4mm
B021
2
Ball Bearing 10x15x4mm
B030
2
Ball Cup
Z125
14
Ball End 4-40 (Black)
Z136
4
Antenna Pipe Set
Z150
1
E Clip E2.5mm
Z241
20
E Clip E2mm
Z242
20
E Clip E3mm
Z243
10
Pin 1.5x8mm
Z262
5
Pin 2x10mm Silve
Z264
10
Binder Head Screw M3x5mm
Z515
6
Binder Head Screw M3x10mm
Z516
6
Binder Head Screw M3x8mm
Z517
10
Flat Head Screw M3x8mm
Z526
6
Tp. Flanged Screw M3x10mm
Z561
6
Tp. Binder Head Screw M3x12mm
Z568
10
Tp. Flat Head Screw M3x8mm
Z576
10
Tp. Flat Head Screw M3x12mm
Z578
10
Tp. Flat Head Screw M3x18mm
Z581
10
Nut M3
Z653
6
Flanged Lock Nut M4
Z684
4
Set Screw M3x10mm
Z705
6
Allen Wrench 1.5mm
Z901
1
Allen Wrench 2.0mm
Z904
1
Cross Wrench (Small)
Z950
1
Turnbuckle Wrench
Z960
1
Pièces détachées
パーツリスト
Ersatzteilliste
De
Nummer Anzahl Beschreibung
341
1
SC-15 Elektronischer Fahrtenregler (Rueckwaerts)
1146
1
FIREBOLT 15T Motor (540er)
3835
2
TE 37 Felge 26mm Weiss (0mm Offset)
3840
2
TE 37 Felge 26mm Weiss (3mm Offset)
3842
2
TE 37 Felge 26mm Chrom (3mm Offset)
3847
2
TE 37 Felge 26mm Chrom (6mm Offset)
4790
2
X-pattern Profil Reifen 26mm D-compound
6122
10
Karosseriesplinte Mittel
6274
1
Angepasster Rammer Grau Rs4
6807
2
Kolbenstange 3 X 31mm
6816
6
Silikon O-ring S10
6819
5
Silikon O-ring P-3 Rot
6831
2
Feder 13x25x1.7mm 7 Wdg. (Schwarz)
6928
1
Ritzel 28z 48dp
6987
1
87z Hauptzahnrad 48dp
72102
2
Daempferkappe 12xm13x0.8mm (lila)
80550
1
HPI TF-1 (AM) Sender
80556
1
HPI RF-1 (AM) Empfänger
80559
1
HPI SF-1 Servo
85000
1
Sprint Querlenker
85001
1
Sprint Diffgehaeuse
85003
1
Sprint Felgenmitnehmer (ax4, Z264x4, Z684x4)
Sprint Rammer (ax1, bx1)
85009
1
85010
1
Sprint Akkuhaltersatz
Sprint Riemenradsatz (ax2, bx2, Z262x2 )
85016
1
Sprint Achsstiftesatz (ax4, bx4)
85021
1
85022
1
Sprint Kegeldiffgehaeuse (ax1,bx1)
85087
1
Hauptchassis Sprint 2
85088
1
Oberdeck Sprint 2
85090
1
Daempferbruecken/karosseriehalter Set Sprint 2
85092
1
Vordere Lenkhebeltraeger (4/6 Grad)/lenkhebel Set
85095
1
Hintere Radtraeger (2 Und 3 Grad) Set Sprint 2
85097
1
Mittelpfosten/servohorn/lenkgestaenge Set Sprint 2
86001
2
Sprint Radachse 5x32mm
86003
1
Elektro Mittelantriebsachse 4x61mm
86004
1
Hauptzahnradadapter (ax1,bx1)
86009
1
Sprint Lenkungs-metallhuelse
86010
1
Sprint Achsstiftehalter (Vorne & Hinten)
86011
1
Sprint Motorplattensatz (ax1,bx1,cx1,dx1,ex1)
86014
1
Kegeldiff Zahnraeder Inkl. Stift (ax2,bx2,cx2)
86015
1
Sprint Kegeldiffachse (ax1,bx1)
86041
1
Riemenspanner Vorne (ax1,bx1, B070x2, Z244x1, Z517x1, Z694x1)
86190
1
Servosafer Bolzen 4x31mm
86191
4
Kugel 4.3x20mm (4-40/schwarz)
86193
2
Knochen 6x41mm
86195
4
Kugel 4.3x4mm (4-40)
86196
4
Kugel 4.3x11.5mm (4-40/inbus/silber)
87006
1
Leichtlauf Riemen S3m 507 Ug 4mm (Vorne/sprint)
87007
1
Leichtlauf Riemen S3m 174 Ug 4mm (Hinten/sprint)
93312
2
Spurstange 4-40x24mm
93317
2
Spurstange 4-40x34mm
A181
1
Servo Saver Huelse
A182
1
Servo Saver Mutter Mit Feder
A183
2
Bolzen 4 X 15mm
A185
1
Lenkstangensatz
A471
2
Daempferteilesatz
A540
2
Sports Daempfergehaeuse 45-56mm
B017
2
Competition Low Friction Kugellager 4x8x3mm
B021
2
Competition Low Friction Kugellager 5x10mm
B030
2
Competition Low Friction Kugellager 10x15x4mm
Z125
14
Kugelpfannen
Z136
4
Kugelkopf 4-40 Schwarz
Z150
1
Antennenrohrset
Z241
20
E-clip E2.5mm
Z242
20
E-clip E2mm Silber
Z243
10
E-clip E3mm
Z262
5
Stift 1.5x8mm
Z264
10
Stift 2x10mm Silber
Z515
6
Flachkopfschraube M3x5mm
Z516
6
Flachkopfschraube M3x10mm
Z517
10
Flachkopfschraube M3x8mm Schwarz
Z526
6
Senkkopfschraube M3x8mm
Z561
6
Schneidschraube Mit Flansch M3x10mm
Z568
10
Flachkopfschneidschraube M3x12mm
Z576
10
Senkkopfschneidschraube M3x8mm
Z578
10
Senkkopfschneidschraube M3x12mm
Z581
10
Senkkopfschneidschraube M3x18mm
Z653
6
Mutter M3
Z684
4
Stoppmutter M4 Mit Flansch
Z705
6
Madenschraube M3x10mm
Z901
1
Inbusschluessel 1.5mm
Z904
1
Inbusschluessel 2.0mm
Z950
1
Kreuzschluessel Klein
Z960
1
Spurstangenschluessel
