  • Page 1 Instruction Manual Bauanleitung Manuel de montage 取扱説明書  Vol.2 117253 VENTURE SBK KIT De Fr...

  • Page 2: Thank You

    ● Thank you for selecting this HPI RACING product! This kit is designed to be fun to drive and uses top quality parts for durability and perfor- mance. The instruction manual you are reading was designed to be easy to follow yet thorough in its explanations. HPI Racing wants you to enjoy driving your new R/C kit.

  • Page 3: En Ne Suivant Pas Ces Instructions

    ● Merci d’avoir choisi ce produit HPI Racing ! Ce kit a été conçu pour être amusant à conduire, et utilise des pièces de la plus haute qualité pour la longévité et les performances. Le manuel d’utilisation qui est entre vos mains a été conçu pour vous fournir des explications faciles à suivre mais complètes. HPI Racing espère que vous aurez plaisir à...

  • Page 4: Table Des Matières

    Contents Inhaltsverzeichnis Table des matières 目 次 Contents Inhaltsverzeichnis Abschnitt Section Contents Page Inhalt Seite Thank you Danke Overview Übersicht Assembly Instruction Montage Anleitung Exploded View Explosionsansicht Parts List Ersatzteileliste Option Parts List Tuningteileliste Table des matières 目 次 Section Table des matières Page セクション...

  • Page 5: Overview

    Overview Vue d’ensemble Übersicht 製品概要 Equipment Needed Équipement nécessaire Benötigtes Zubehör 用意するもの Radio Components Fernsteuer Anlage Éléments de la radio プロポコンポーネント You will need a 2-channel radio system with servo, electronic speed control and battery pack. Sie benötigen eine 2-Kanal RC-Anlage, ein Servo, einen elektronische Fahrtenregler und Fahrakkus. 2チャンネル送信機、受信機、サーボ、ＥＳＣ、走行用バッテリー、送信機用バッテリー、走行用バッテリー充電器を準備してください。...

  • Page 6: Éléments Inclus

    Tools Werkzeuge Outils 工具 Tools needed for assembly. sold separately. Zum Zusammenbau benötigtes Werkzeug. Separat erhältlich. Outils nécessaires pour la mise en place, vendus séparément. 本製品を組立てるには下記の工具が必要です。別途ご用意ください。 Z950 Cross Wrench Kreuzschlüssel Needle Nosed Pliers Clé en croix Flachzange ミニクロスレンチ Ball end ラジオペンチ...

  • Page 7: Assembly Instruction

    Assembly Instruction le mode d’emploi pour l’assemblage Montage Anleitung シャーシの組み立て Open Bag A Tüte A öffnen Ouvrir le sachet A Bag Aを開封します。 67438 Ball Bearing 8x14x4mm 8 14 4 Z159 Thread Lock Schraubensicherung ネジロック剤 116869 114761 Button Head Screw M2.5X6mm 116870 67438 Diff Ring 43T...
  • Page 8 Make 2 2 fois 2 Stück 2個作ります 115942 Cross Joint Grease Fett Graisse グリス 115942 CVD Axle 115942 Drive Shaft 78mm 115942 Retainer 115942 Pin 2x10 Z353 Z353 Button Head Screw M3x10mm Button Head Screw M3x10mm Right Droite Left Gauche Rechts Links 右...
  • Page 9 117356 116877 117356 Z353 Button Head Screw M3x10mm 116868 116882 Flange Bushing Left Gauche Links 左 Z353 Button Head Screw M3x10mm Right Droite Rechts 右 Z700 Set Screw M3x3mm Z264 Pin 2x10mm Z700 Set Screw M3x3mm Z353 Button Head Screw M3x10mm Z264 Pin 2x10mm 116868...
  • Page 10 Z353 Button Head Screw M3x10mm B022 Ball Bearing 5x11x4mm 117086 Axle Weights (12g ea.) 116867 Z164 Grease Fett Graisse グリス B022 117086 Ball Bearing 5x11x4mm Axle Weights (12g ea.) 116884 Link Ball 116867 116865 Button Head Screw M2.5x25mm 116867 116866 Needle Nosed Pliers Flachzange ラジオペンチ...
  • Page 11 Z353 Button Head Screw M3x10mm Z159 Thread Lock Schraubensicherung 116871 ネジロック剤 116871 116871 116871 Z351 Button Head Screw M3x6mm Z164 Grease Z351 Button Head Screw M3x6mm Z351 Button Head Screw M3x6mm B022 Ball Bearing 5x11x4mm Z164 Grease B022 Ball Bearing 5x11x4mm Z351 Button Head Screw M3x6mm...

  • Page 12: Open Bag B Tüte B Öffnen Ouvrir Le Sachet B

    Z676 Lock Nut M3 Thin Type 116885 Z354 Z676 116885 Steering Flange Ball Z354 Button Head Screw M3x12mm Open Bag B Tüte B öffnen Ouvrir le sachet B Bag Bを開封します。 67438 Ball Bearing 8x14x4mm 8 14 4 Z159 Thread Lock Schraubensicherung ネジロック剤...
  • Page 13 Z242 E Clip E2mm 116877 116870 Input Gear 13T Z353 Button Head Screw M3x10mm B022 Ball Bearing 5x11x4mm 117086 Axle Weights (12g ea.) 116867 Z164 Grease Fett Graisse グリス B022 117086 Ball Bearing 5x11x4mm Axle Weights (12g ea.)
  • Page 14 117356 116865 Button Head Screw M2.5x25mm 116867 116866 116864 Button Head Screw M2.5x20mm Z353 Button Head Screw M3x10mm Z159 Thread Lock 116871 116871...

  • Page 15: Open Bag C Tüte C Öffnen Ouvrir Le Sachet C

    Z351 Z700 Button Head Screw M3x6mm Set Screw M3x3mm 116875 116868 Z264 Z164 Pin 2x10mm 116874 Grease Z351 B022 B022 Ball Bearing 5x11x4mm Z164 Grease 116874 Z351 Z700 116868 116875 Z264 Z351 116874 Rear Axle Shaft Open Bag C Tüte C öffnen Ouvrir le sachet C Bag Cを開封します。...
  • Page 16 117356 117356 100554 Set Screw M3x14mm 117357 Aluminum Suspension Link 6x93.5mm A133 117079 Aluminum Link 6x82mm A133 Z159 Thread Lock A133 Ball 5.8x6mm A133 A133 116844 Front Upper Link 6x104mm 116884 Needle Nosed Pliers Link Ball Flachzange V bi d ラジオペンチ...

  • Page 17: Open Bag D Tüte D Öffnen Ouvrir Le Sachet D

    Open Bag D Tüte D öffnen Ouvrir le sachet D Bag Dを開封します。 Z262 Pin 1.5x8mm 116859 116859 105817 Z262 105805 Pin 1.5x8mm 105805 116842 Screw Shaft M3X2.4x11mm 105811 105805 105805 Z159 Thread Lock 105817 B030 106720 Ball Bearing 10x15x4mm 106720 106860 Adjusting the Slipper Clutch Réglage de l’embrayage...
  • Page 18 Z353 Button Head Screw M3x10mm Z164 Grease 116857 116858 116859 B021 Ball Bearing 5x10x4mm 116858 Z216 Button Head Screw M3x15mm 116855 Z356 Button Head Screw M3x18mm...
  • Page 19 116858 Z353 B021 Ball Bearing 5x10x4mm Z352 Button Head Screw M3x8mm Z353 Button Head Screw M3x10mm Z352 Button Head Screw M3x8mm Z700 Set Screw M3x3mm 116848 116848 Z352 Button Head Screw M3x8mm Z353 Button Head Screw M3x10mm...

  • Page 20: Steering Servo

    Refer to radio manufacturer's instruction for proper installation and verify servo neutral position. Schauen Sie für den korrekten Einbau und das Einstellen der Neutralposition in die Anleitung Ihrer Fernbedienung. Se reporter au manuel de votre radio pour des instructions détaillées. 送受信機の取扱説明書を参考に配線し、サーボのニュートラル設定をします。...

  • Page 21: Proper Spur Gear Mesh Korrektes Ritzelspiel Engrènement Correct De La Couronne

    116858 Z352 Button Head Screw M3x8mm Z700 Set Screw M3x3mm 6916 Pinion Gear 16 Tooth Z542 Cap Head Screw M3x8mm Proper Spur Gear Mesh Korrektes Ritzelspiel Engrènement correct de la couronne バックラッシュの調節 Adjust the motor position to get proper gear mesh. To get a perfect gear mesh, place a piece of paper between the gears and tighten the motor mount screws.
  • Page 22 107373 Button Head Screw M2.5x10mm 116848 Z244 B022 E Clip E4mm 116863 Z245 E Clip E5mm Z263 B022 Pin 2x8mm Ball Bearing 5x11x4mm Z164 Grease 116863 B022 B023 Ball Bearing 6x13x5mm B022 116863 Z264 Z264 Pin 2x10mm B023...

  • Page 23: Open Bag E Tüte E Öffnen Ouvrir Le Sachet E

    Z354 Button Head Screw M3x12mm Z354 Button Head Screw M3x12mm Z159 Thread Lock 116842 Screw Shaft M3X2.4x11mm Open Bag E Tüte E öffnen Ouvrir le sachet E Bag Eを開封します。 Z242 E Clip E2mm Make 4 4 fois 4 Stück 4個作ります 117047 108315 117047...
  • Page 24 117047 Silicone Oil Silikon Daempferoel Huile silicone シリコンオイル 117340 O-Ring 1.5 x 6.50 Use a Rag. Verwenden Sie einen Putzlappen. Utilisez un chiffon. オイルを拭き取ります。 Move the shaft up and down slowly to remove all air bubbles. Bewegen Sie die Kolbenstange langsam nach oben und unten, damit Luftblasen entweichen können.
  • Page 25 Open Bag F Tüte F öffnen Ouvrir le sachet F Bag Fを開封します。 116849 Pin 1.5x11mm 116850 Z164 Grease 116847 116850 116847 Z159 Z164 Thread Lock Grease 116847 116847 Z159 Thread Lock 113719 Flat Head Screw M2.5x8mm...

  • Page 26: Open Bag G Tüte G Öffnen Ouvrir Le Sachet G

    Open Bag G Tüte G öffnen Ouvrir le sachet G Bag Gを開封します。 Z663 Lock Nut M3 116845 116845 116845 116845 Z356 Button Head Screw M3x18mm 116841 116841 Z352 Button Head Screw M3x8mm 116841 116848 116845 116841 Z356...
  • Page 27 Z676 100556 Lock Nut M3 Thin Type Flat Head Screw M3x14mm Z084 Flat Head Screw M3x12mm 116843 Z352 Button Head Screw M3x8mm 100556 116843 Z084 116842 Screw Shaft M3X2.4x11mm Z159 Thread Lock...
  • Page 28 Z164 116846 Grease Z083 Flat Head Screw M3x10mm Die Akkuhalterung kann an verschiedene Akku-Typen angepasst werden. 116851 Stick Pack Type Battery Le support de batterie peut être adapté à différents types de batterie Stick-Pack Akku 各種バッテリー形状に合わせて搭載方法が選択できます。 Batterie forme "stick" パックタイプバッテリー Li-Po Battery LiPo Akku Batterie...
  • Page 29 100556 Flat Head Screw M3x14mm 116843 116843 100556 Z353 Z085 Z353 Flat Head Screw M3x15mm 116881 Z353 Button Head Screw M3x10mm...
  • Page 30 Z159 Thread Lock 116842 Screw Shaft M3X2.4x11mm Z354 Button Head Screw M3x12mm Z676 Lock Nut M3 Thin Type 116884 Link Ball Z354 Button Head Screw M3x12mm Z159 Thread Lock Z216 Button Head Screw M3x15mm...
  • Page 31 Z216 Z216 Z357 Button Head Screw M3x20mm Z216 Button Head Screw M3x15mm 116842 Screw Shaft M3X2.4x11mm Z354 Button Head Screw M3x12mm...
  • Page 32 Z538 Cap Head Screw M3x25mm Z663 Lock Nut M3 Z216 Button Head Screw M3x15mm Z357 Button Head Screw M3x20mm Z216 Z357...

  • Page 33: Open Bag H Tüte H Öffnen Ouvrir Le Sachet H

    Open Bag H Tüte H öffnen Ouvrir le sachet H Bag Hを開封します。 Z356 Z354 Z663 Lock Nut M3 Z354 Button Head Screw M3x12mm Z356 Button Head Screw M3x18mm...
  • Page 34 116842 Screw Shaft M3X2.4x11mm 116841 116841 116842 116856 116856 75106 Body Clip (6mm) 116856 116856 75106...
  • Page 35 Optional body mount for high roof body. Optionale Karosseriehalterung für sehr hohe Karosserien. Option de montage de la carrosserie pour carrosserie à toit haut. ハイルーフボディ用ボディマウント 107373 Button Head Screw M2.5x10mm 116856 116856 116856 116856 75106 Body Clip (6mm) 107373 116856 75106 100556 Flat Head Screw M3x14mm...

  • Page 36: Exploded View

    Exploded View Vue éclatée Explosionsansicht 展開図 106860 Z352 106720 Z352 Z352 116858 116842 106720 Z353 Z353 B030 117050 117047 105805 105811 105817 117340 105805 105809 B021 Z352 Z242 105805 117047 Z356 B021 116858 Z242 117047 105805 116858 Z262 105817 116858 116859 108315 117049...
  • Page 37 75106 116842 116856 116842 75106 116841 116855 Z357 116842 116841 Z356 Z356 116856 75106 116842 Z216 116856 116845 107373 116841 100556 Z663 100556 116881 75106 116845 Z663 116856 116845 Z663 116842 Z663 107373 116841 116845 116842 Z357 116856 Z356 116841 Z356 116843 100556...

  • Page 38: Pièces Détachées

    Parts List Pièces détachées Ersatzteilliste パーツリスト Parts List Parts # Description Parts # Description 6121 Body Pin (4mm/Black/Small/20Pcs) 116870 Diff Ring/ Input Gear Set (43/13) 6819 Silicone O-Ring P-3 (Red/5Pcs) 116871 Lower Shock Mount Set 6916 Pinion Gear 16 Tooth (48 Pitch) 116872 Panhard Rod/Lower Shock Mount 67438 Ball Bearing 8X14X4mm (2Pcs)

  • Page 39: Ersatzteileliste

    Ersatzteileliste Nummer Beschreibung Nummer Beschreibung 6121 Karosserieklammern (4mm/Schwarz/20St) 116870 Diff Zahnraeder Set (43Z/13Z) 6819 Silikon O-Ring P-3 (Rot/5St) 116871 Daempferhalterung Unten Set 6916 Ritzel 16 Zaehne (48Dp) 116872 Panhard-Stab/Daempferhalterung Unten 67438 Kugellager 8X14X4mm (2St) 116874 Hinterachs-Welle (2St) 75106 Karosserieklammern (6mm/Schwarz/20St) 116875 Felgenmitnehmer 12mm Mit Sicherung (4St) 86955 Silikon-Daempfer-Oel 30Wt (60Ccm)

  • Page 40: Pièces Dètachèes

    Pièces Dètachèes Nummer Beschreibung Nummer Beschreibung 6121 Clip carrosserie (4mm/noire/petit/20p.) 116870 Joint differentiel/ens entree d'engrenage (43/13) 6819 Joint torique silicone p-3 (rouge/5p.) 116871 Support amortisseur inferieur 6916 Pignon 16 dents (48 dp) 116872 Barre panhard/support amortisseur inferieur 67438 Roulement a billes 8x14x4mm (2p.) 116874 Arbre d’axe arriere (2pcs) 75106 Clip carrosserie (6mm/noir/moyen/20p.)
  • Page 41 スペアパーツリスト 日本語 品 番 品 名 品 番 品 名 6121 ボディピン小 (4mm/ブラック/20pcs) 116870 デフリング/インプットギアセット (43/13) 6819 シリコンＯリング P-3 (レッド/5pcs) 116871 ロアショックマウントセット 6916 ピニオンギア 16T (48P) 116872 パンヘッドロッド/ロアショックマウントセット 67438 ボールベアリング8x14x4mm（2pcs） 116874 リアアクスルシャフト(2pcs.) 75106 ボディーピン (6mm/ブラック/20pcs) 116875 ロックタイプ六角ハブ 12mm (4pcs) 86955 PRO シリコンショックオイル...

  • Page 42: Option Parts List

    Option Parts List Liste des pièces optionnelles Tuningteileliste オプションパーツリスト 115959 116241 116242 116445 Spool Output Gear Set Aluminum Front Hub Set Aluminum Straight Axle Adapter Set (Rear) Aluminum Servo Horn 23 Starrachsen Ausgangs Getriebe Set Achseladapterset aus Aluminium (hinten) Aluminium-Servohorn 23 Aufnahmenset Aluminium (vorne) Engrenage de sortie de tiroir Adaptateur d’essieu droit en aluminium (arrière)
  • Page 43 115546 110608 9084 92550 PRO-SERIES TOOLS BODY REAMER PRO-SERIES TOOLS (TEMP-DRIVER) CURVED SCISSORS HPI CARRYING BAG (XL/SAVAGE SIZE/BLACK) KAROSSERIELOCHBOHRER PRO-SERIE PRO-SERIES TOOLS (TEMP-DRIVER) LEXANSCHERE HPI TRAGETASCHE (XL/SAVAGE GROESSE/SCHWARZ) OUTILS PRO-SERIES ALESOIR PRO-SERIES TOOLS (TEMP-DRIVER) CISEAUX LEXAN SAC DE TRANSPORT HPI (XL/TAILLE SAVAGE/NOIR) PROシリーズツール...
  • Page 44 HPI RACING LTD. Serial Number Seriennummer 19 William Nadin Way, Numéro de série Swadlincote, Derbyshire, シリアルナンバー DE11 0BB, UK +44 1283 226570...
