10.4.5 NET/TOTAL & Accumulation Mode.
The Net/total function allows the user to add number of items consecutively and to see the
total of all the net weights, the value of which is displayed on smaller digits above the main
display. The current net weight is shown on the main display. The [Tare] key functions the
same way as when in normal weighing mode. Using NET/TOTAL, you can only load items
up to the maximum capacity of the balance. A report can then be printed showing the weight
of each individual item and the total weight.
Accumulation allows you to add items which are each less than the maximum capacity of
the balance, record the weight and then remove them. You can then tare the balance, add
another weight and record it. The total sum of stored weights will be displayed on the upper
display line. This process can be repeated continuously until you have weighed all required
samples. Total accumulated weight can be much greater than the maximum capacity of the
balance, and is only limited by the units selected and the number of display digits available.
Steps:
NET/TOTAL
• Press [Mode] and then [Up] or [Down] to select "
press [Select] to enter the function. The display will show zeros in both main and
upper display areas, accompanied by "
balance is in the Net/Total mode.
• Place the first item. The net weight will be displayed in the main display and the upper
display line will still display zeros.
• Press [Select]. The main display will show zeros and the upper display line will show
the first net weight as total net weight.
• Place a second item on the pan without removing the first one. The main display will
show the weight of the second item. Pressing [Select] will zero the main display and
the upper display line will now show the total weight of both of the items.
• Continue adding required items to the pan, as above.
• When finished, press [Mode] to display the total of the net weights to the main display
NET TOT NET TOT NET TOT NET TOT
e.g. " XXX.XXX g".
Pressing [Print] will print a report to a connected device which contains individual net
weights followed by the final net weight total.
e.g.:
NET / TOT
Ser No: AE9U0123
ID No: 1
Date: 14/07/2015
Time: 15:00:03
Net 01: 1.234 g
Net 02: 5.678 g
Net 03: 9.123 g
Total: 16.035 g
© Adam Equipment Company 2015
NEt TOT NEt TOT NEt TOT NEt TOT
" for Net/Total mode. Now
NT NT
NT NT
" in the upper display line to indicate that the
