MB EVO PRO/MB EVO
NOTICE
• Maintenance and cleaning work may be carried out only by qualified personnel (in
Germany see TRBS 1203).
• Always wear your personal protective equipment when performing maintenance and
cleaning work.

8.1 Replacing wear parts

NOTICE
• Order data and ID numbers for the equipment parts, wear parts and accessories can be
found in the current ABICOR BINZEL price lists for spare and wear parts.
www.binzel-abicor.com
• Use the ABICOR BINZEL switch key wrench to mount and disassemble the wear parts,
and make sure that the connections are properly assigned.
Replace wear parts in accordance with the figures below:
1 2
1 Gas nozzle 2 Contact
tip
Fig. 11 Type 15/25
2
1
1 Gas nozzle 2
Fig. 12 Type 24/26/36/240D
BAL.0414.0 • 2019-05-17
3
3 Gas nozzle holder 4
3
Contact tip 3 Tip adaptor
8 Maintenance and cleaning
4 5
Tip adaptor 5
4
4 Gas diffuser
6
Retaining spring 6 Torch neck
5
5 Torch neck
EN - 15
