Assembly and Operating Instructions
Connection as a group controller
Attention
If the control is used as a group control device, for example, no bridge
can be inserted between the L and C terminals!
1..Remove.the.protective.caps.
..Connect.the.power.supply.unit.to.the.UCR50.as.follows:
3..Put.the.protective.caps.back.on.the.power.supply.unit.
4..Fix.the.power.supply.unit.in.the.box.
5..Put.the.operating.device.in.the.frame.and.plug.it.into.the.power.supply.unit.
