c) Changing/mounting the wheels
The tyres are fixed on the wheel rim and cannot be removed. If a tyre is worn, the entire wheel must be replaced.
Loosen and remove the wheel nut (A) with a suitable
socket wrench. Then remove the lock washer (B) from the
wheel axle (D).
Remove the wheel by pulling it off of the wheel axle (D).
Attach the new wheel so that the hex socket on the inside
of the wheel rim fits exactly over the wheel hub nut (C).
Place the lock washer (B) on the wheel axle (D) and screw
the wheel to the wheel axle with the wheel nut (A) that you
previously removed.
Do not apply any force when tightening the wheel nut, oth-
erwise the wheel will not spin freely and the powertrain
may be damaged.
When you remove the wheel, the wheel hub nut (C) may accidentally get stuck in the wheel rim or become
detached from the wheel axis (D). Ensure that the drive pin (E) does not fall off.
If the wheel is subsequently re-fitted, it is important to check that the drive pin (E) is inserted exactly into the
centre of the wheel axle (D) and that it is positioned in the corresponding notch on the wheel hub nut (C).
If the drive pin (E) is missing, no torque can be transferred from the motor to the wheel and the wheel will
spin freely.
