MODEL DESIGNATION

Heated Well Built-In
No Character = Standard Wattage
I = Insulated Top Mount
IB = Insulated Bottom Mount
RT = Thermostat Control (UR only)
RN = Infinite Switch Control (UR only)

MODEL DESCRIPTION

All Models

All Built-In Heated Well units are reliable and versatile. Units
have a stainless steel and aluminized steel housing with a metal
sheathed heating element that is available in low, standard, and
high wattage.
Heated Wells can be supplied with the heating element
controlled in one of two ways. The first is UL listed with a
thermostatic control and an ON/OFF switch housed in a
remote control enclosure. The control enclosure is connected
to the unit with a 36" (914 mm) flexible conduit assembly (72"
[1829 mm] flexible conduit connection is optional, not available
for retrofit). The second is a remote switch option that is UL
recognized (UR) with either a thermostatic control and an ON/
OFF switch or an infinite switch control with indicator light.
The thermostatic control and ON/OFF switch is connected to
the unit with a 36" (914 mm) flexible conduit assembly (72"
[1829 mm] flexible conduit connection is optional, not available
for retrofit).
Built-In Heated Wells can be hardwired directly to a power
source for a secure and cord free serving area. Corded units
also are available. EZ locking hardware allows for Heated
Wells to be mounted into non-combustible countertops and
combustible countertops using a Hatco mounting kit accessory.
Built-In Heated Wells are designed, manufactured, and tested
to maintain safe food holding temperatures.
HWB-FUL Models
HWB-FUL models are capable of holding a variety of pan
combinations listed below. These models are designed to
be mounted to the topside of a non-combustible countertop
or topside of a combustible countertop using the appropriate
countertop mounting kit.
• One full size pan.
• Three 1/3 size pans with adapter bars.
• Two 1/2 sized pans with adapter bars.
• Two 7 quart (7 L) round pans with adapter top.
• Three 4 quart (4 L) round pans with adapter top.
An optional remote control enclosure with a digital temperature
controller and an ON/OFF switch is available.
Pans, Covers, Adapter Bars, and Adapter Tops sold separately
(see the OPTIONS AND ACCESSORIES section for details).
H W B x x x - x D A
H = High Wattage
L = Low Wattage
Auto-Fill Equipped
Drain Equipped
FUL = Full Size Pan
43 = 4/3 Size Pan
4QT = Round 4 Quart (4 L) Pan
7QT = Round 7 Quart (7 L) Pan
11QT = Round 11 Quart (10 L) Pan
HWB-FUL Model
HWB-FULD Models
HWB-FULD models have the same capabilities as the HWB-
FUL but are equipped with a drain. The drain includes a 3/4"
NPT drain fitting and flat drain screen that allows for pans
to stay level for consistent temperatures. These models are
designed to be mounted to the topside of a non-combustible
countertop or topside of a combustible countertop using the
appropriate countertop mounting kit.
HWB-FULDA Models
HWB-FULDA models have the same capabilities as the HWB-
FULD but are equipped the optional Auto-Fill feature. The
Auto-Fill feature fills and maintains the proper level of water
in the well automatically. These models are designed to be
mounted to the topside of a non-combustible countertop or
topside of a combustible countertop using the appropriate
countertop mounting kit.
HWBI-FUL Models
HWBI-FUL models are the same as the HWB-FUL models
except the units are fully insulated. The insulated unit conserves
energy and preserves more consistent heating temperatures.
These models are designed to be mounted to the topside of
a non-combustible countertop or topside of a combustible
countertop using the appropriate countertop mounting kit.
HWBI-FULD Models
HWBI-FULD models are top mount insulated versions that have
the same capabilities as the HWBI-FUL but with a drain. The
drain includes a 3/4" NPT drain fitting and flat drain screen that
allows for pans to stay level for consistent temperatures. These
models are designed to be mounted to the topside of a non-
combustible countertop or topside of a combustible countertop
using the appropriate countertop mounting kit.
