Introduction
Static electricity can cause damage to printed circuit boards (PCBs). Use correct
precautions when you touch PCBs.
Keep PCBs in antistatic containers.
Put on a grounded wrist strap when you touch PCBs.
This Field Service Bulletin gives the procedure for installing an internal machine interface
receptacle, cables, and voltage divider printed circuit board (PCB).
Tools and materials
Assorted Phillips

Grounded wrist strap (or similar grounding accessory)

Kit 428653 contents
Part number
075534
223476
074391
Powermax45 XP Field Service Bulletin
WARNING
ELECTRIC SHOCK CAN KILL
Disconnect electrical power before doing installation or maintenance.
All work requiring removal of the plasma power supply outer cover or panels
must be done by a qualified technician.
See the Safety and Compliance Manual (80669C) for more safety
precautions.
NOTICE
® , TORX ® , and blade screwdrivers
Description
Plastite #6 X 5/16 pan head screw
Machine interface receptacle with cables and voltage divider PCB
Cable holder
809940
Machine Interface Receptacle with Voltage Divider Board
Quantity
2
1
2
3
