Cold junction compensation ....................... < ±1.0°C
Sensor error detection ................................ Yes
Sensor error current:
When detecting .................................... Nom. 33 mA
Else ...................................................... 0 mA
Voltage inputs:
Measurement range .................................... -12...150 mV
Min. span ..................................................... 5 mV
Input resistance ........................................... 10 MΩ
Outputs:
Current outputs:
Signal range ................................................ 4...20 mA
Min. signal range ......................................... 16 mA
Updating time .............................................. 440 ms
Output signal at EEprom error .................... ≤ 3.5 mA
Load resistance ........................................... ≤ (V
Load stability .................................................... < ±0.01% of span / 100 Ω
Sensor error detection:
Programmable ............................................. 3.5...23 mA
NAMUR NE43 Upscale ............................... 23 mA
NAMUR NE43 Downscale ........................... 3.5 mA
Ex / I.S. data:
Output, terminal 11...13, (21...23):
U i ................................................................. : 28 VDC
I i .................................................................. : 120 mADC
P i ................................................................. : 0.84 W
L i ................................................................. : 10 µH
C i ................................................................. : 1.0 nF
Input, terminal 41...44, (51...54):
U o ............................................................... : 9.6 VDC
I o ................................................................. : 25.1 mADC
P o ................................................................ : 60.3 mW
L o ................................................................ : 45 mH
C o ................................................................ : 3.5 µF
20
All manuals and user guides at all-guides.com
- 7.2) / 0.023 [Ω]
supply
EEx / I.S. approval:
DEMKO 99ATEX126960 ..............................
Max. amb. temperature for T1...T6 ............. 60°C
Applicable in zone ....................................... 0, 1, or 2
GOST R approval:
Standard: VNIIM .......................................... Cert. no. Ross DK.ME48.V01899
Ex: VNIIFTRI ................................................ Cert. no. Ross DK.GB06.V00100
Observed authority requirements:
EMC 2004/108/EC
Emission and immunity ........................ EN 61326
ATEX 94/9/EC .............................................. EN 50014 and EN 50020
Of span = Of the presently selected range
II 1 G
EEx ia IIC T1...T6
Standard:
21
